Monitor Audio

Monitor Audio Cinergy 100, wall speaker

€2,815.00 EUR

Monitor Audio Cinergy 100, wall speaker - Ask you before buying whether we have this item in a warehouse if we do not have to be ordered and arrive within 2-21 days.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

Whether mounted on the wall or integrated into it, the Monitor Audio Cinergy 100 provides exceptional sound in your cinema space.

  • Recommended amplifier power: 2 00 - 800 W.
  • Sensitivity: 89 dB.
  • Resistance: 4 ohms.


DESCRIPTION

Unique isolation options separate the speaker from surfaces around it, reducing vibrations for purer sound and a truly cinematic experience. Removable port bungs give your installer the power to tailor the bass response to you. And thanks to precise equalizer settings for use with Monitor Audio's Amplifiers, it's possible to fine-tune your listening experience even further.

Key Features
  • Unique isolation options reduce unwanted vibrations by up to 18dB for a professional cinema experience
  • Rotatable mid-tweeter array for use vertically or horizontally
  • Numerous mounting options, with a design perfectly suited to custom built mounting behind an acoustically transparent screen
  • Removable port bungs to tailor the bass response along with EQ profiles for use with Monitor Audio Installation Amplifiers
  • MPD high-frequency transducer with accuracy, clarity and lifelike sound
  • C-CAM mid-range driver with high power handling, high sensitivity, wide directivity
  • RDT II Bass driver with exceptional high-power handling, high sensitivity, high excursion and low distortion
  • Crossover with performance of the highest level, even when pushed hard for long periods of time
  • Magnetic grills to hide drivers and prevent visual reflections from brightly lit cinema screens


TECHNICAL DATA

SPECIFICATIONS

THX Certified

THX® Certified Ultra

System Format

3 Way

Sensitivity (2.83 Vrms @ 1 M)

89 dB

Maximum Linear SPL**** (@1m, free space)

Continuous 103 dB, Peak 116 dB

Power Handling (RMS)

Continuous 200 W, Peak* 800 W

Nominal Impedance

4 Ohms

Minimum Impedance (20 Hz - 20 kHz)

3.8 Ohms

Recommended Low Frequency Crossover Frequency

80 - 100 Hz (High Pass)

Recommended Amp Requirements (RMS)

100 - 800 W (IA750-2 or IA750-4)

Bass Alignment

ported**

Port Tuning Frequency

67Hz**

LF Extension, In Wall, With Port Bungs (- 6dB)

48 Hz

LF Extension, In Free Space, No Port Bungs (- 6dB)

65 Hz

HF Extension (-6dB)

>30 kHz

Drive Unit Complement

1 x 8" RDT Driver
1 x 2.5" C-CAM Driver
1 x MPD Transducer

External Dimensions (Cabinet Only (H x W x D))

460 x 350 x 160mm (18 1/8 x 13 3/4 x 6 5/16 ")

External Dimensions (Inc Grille) (H x W x D)

460 x 350 x 174.1 mm (18 1/8 x 13 3/4 x 6 7/8 ")

Weight

18.4 kg (40 lb 8 oz)

Conditions

* Calculated from a peak voltage, this is not a true power figure but useful for comparisons.

** When used in an In-Wall or On-Wall configuration it is recommended to use the fitted port bungs to control bass output. This will effectively make the product a sealed box.

*** Band limited with Low pass at 200 Hz, should only be used with IA800-2C and the correct speaker profile.

**** Tested with a music like noise signal with distortion and power compression remaining below audible limits.

thx

THX® Certified Loudspeakers.

THX® and the THX® Logo are the property of THX® Ltd., registered in the US and other countries.
DOCUMENTS

INSTRUCTIONS

User Manual (EN).
