Skaitmeninis stiprintuvas su procesoriumi Helix Match PP 82DSP

599.00 €

Pristatymas į namus nuo 4.99 €

Venipak kurjeriu per 1-2 darbo dienas.

Atsiimkite parduotuvėje 0 €

Armatūrininkų g. 1, Kaunas
Darbo laikas: I-V 9:00-18:00

8 kanalų "Plug & Play" stiprintuvas su integruotu DSP, USB sąsaja ir 2 RCA išėjimais.

  • Galia RMS / MAX:
    prie 2 Omų 8 x 70W  /  8 x 140W
    prie 4 Omų 8 x 55W  /  8 x 110W
  • Dažnių diapazonas: 20 Hz - 22,000 Hz
  • DSP raiška: 56 Bit
  • Jautrumas: 100dB
  • DSP apdorojimo galia: 172 MHz
  • Damping faktorius: > 100
  • Įėjimo varža: 30 Omai
  • Matmenys: 44 x 185 x 164 mm  /  Svoris: 2,60 kg
  • Proprietary Class HD Technology for peerless sensitivity and minimal heat generation
  • 8 separate configurable amplifier channels for maximum flexibility
  • Extremely powerful DSP with virtually limitless sound adjustment options freely configurable via PC-Tool software
  • 56 Bit DSP technology and 24 Bit AD/DA converter from BurrBrown
  • Optical S/PDIF input 6 – 96 kHz with an integrated sample rate converter
  • USB-on-board for direct connection to a PC
  • Freely configurable 2-channel PreOut for the connection of additional amplifiers
  • AUX input with automatic or manual switchover
  • Start-Stop capable down to 6 Volts supply voltage
  • Latest D/A converter-controlled P³S power supply technology with "ECO Mode"
  • Control input for optional cable remote control, functionality configurable via PC software
  • State-of-the-art SMD technology for a more compact design and maximum reliability
  • Six-layer printed circuit boards in multilayer technology for the best possible power and signal trans mission

The crown of the Plug & Play amplifier series – with its incredible performance capabilities on an ultra-small footprint, the PP 82DSP outshines all the previous models that came before it. With its enormous range of functions, thanks to Audiotec Fischer´s unique Class HD technology, it is setting a whole new standard in terms of efficiency. The combination of state-of-the-art digital amplifier technology and a dynamically-controlled switched-mode power supply reduces heat generation and power consumption to an absolute minimum. But that´s not all - no less than eight separate and freely-configurable amplifier channels with incredible power enable even sophisicated system configurations with one single amplifier.

Skaitmeninis stiprintuvas su procesoriumi Helix Match PP 82DSP Stiprintuvai Helix AUTOGARSAS.LT
Helix

Skaitmeninis stiprintuvas su procesoriumi Helix Match PP 82DSP

599.00 €

8 kanalų "Plug & Play" stiprintuvas su integruotu DSP, USB sąsaja ir 2 RCA išėjimais.

DOKUMENTAI

Vartotojo vadovas (EN)

DSP PC-Tool software

FEATURES

APRAŠYMAS

The crown of the Plug & Play amplifier series – with its incredible performance capabilities on an ultra-small footprint, the PP 82DSP outshines all the previous models that came before it. With its enormous range of functions, thanks to Audiotec Fischer´s unique Class HD technology, it is setting a whole new standard in terms of efficiency. The combination of state-of-the-art digital amplifier technology and a dynamically-controlled switched-mode power supply reduces heat generation and power consumption to an absolute minimum. But that´s not all - no less than eight separate and freely-configurable amplifier channels with incredible power enable even sophisicated system configurations with one single amplifier.
