SVS SoundPath Tri-Band Wireless Audio, bevielis imtuvas ir siųstuvas

SoundPath Tri-Band Wireless Audio bevielio siųstuvo-imtuvo rinkinys naudojamas apjungti kolonėles bevieliu būdu neprarandant kokybiško garso bei siekiant statyti kolonėles neįprastose vietose.

• Dažnių juosta: 6Hz – 20 kHz +/- 0.5 dB.
• Veikimo dažnis: 2.4 GHz, 5.2GHz, 5.8 GHz.
• Veikimo atstumas: 39 m.
• Signalo vėlavimas: 19 ms.

APRAŠYMAS

Optimized for congested wireless environments, the SVS SoundPath Tri-Band Wireless Audio Adapter expands SVS’ range of full-range wireless audio adapters. In most systems, the more affordable SVS SoundPath Wireless Audio Adapter is sufficient, however, if you have a wireless environment prone to interference from other devices, the Tri-Band version is better suited for pristine signal transfer without interference.

The SVS SoundPath Tri-Band Wireless Audio Adaptor reduces cable clutter without sacrificing performance. Wirelessly connect a subwoofer, stereo zone of powered speakers, powered surround sound speakers, and other components in just minutes. Transmits a full-range (6Hz – 20 kHz) stereo signal up to 130-feet (line-of-sight).

By auto-switching between the 2.4 GHz, 5.2 GHz, and 5.8 GHz wireless bands, the adapter operates flawlessly in the most crowded wireless environments. Uncompromised sound quality, less cable clutter, and no more interference from security cameras, Bluetooth devices, smart TVs, WiFi mesh networks, or other wireless devices.

SoundPath Tri-Band Wireless Audio Adapter

Transmits a pristine LFE or full-range stereo audio signal up to 130-feet at 16-bit/48KHz with ultra-low latency. Tri-Band technology auto-switches between three wireless bands for use in crowded wireless signal areas where single-band wireless transmitters are prone to interference. Wirelessly connects subwoofers, powered speakers, and more.

Setup of the SoundPath Tri-Band Wireless Audio Adapter takes minutes. Once installed, it auto-switches between the 2.4 GHz, 5.2 GHz, and 5.8 GHz wireless bands for uninterrupted audio signal transfer. Impervious to interference from Bluetooth, Wi-Fi routers, wireless security systems, cameras, and other wireless devices.

TECHNINIAI DUOMENYS

SPECIFIKACIJOS

Transmitter:

• Analog input level: maximum 2Vrms
• Minimum power: 5V @0.5A

Receiver:

• Analog output level: maximum 1Vrms
• Minimum power requirement: 4.75V @0.3A

Key Specifications:

• Dimensions: W 3.15" (80mm) x D 2.36" (60mm) x H 1.02 (26mm)
• Weight: 1.25 lbs
• Deters against against both in and out of band sources of interference, including: microwaves, wireless cameras, cordless phones, Bluetooth devices and more
• Operates seamlessly alongside 802.11b/g/n Wi-Fi
• Automatic receiver antenna diversity minimizes fading and multi-path effects
• Seamless RF band/channel switching
• RF Band – Tri-Band (auto switching) (2.4/5.2/5.8 GHz) – finds the best solution and connects
• Three RF frequency ranges for each frequency band:
• Band 1: 2400-2483.5MHz
• Band 2: 5150-5250MHz
• Band 3: 5725-5875MHz
• 22 Mbps wireless air data rate
• Sample Rate: 48kHz
• THD+N: -70dB (10Hz – 20kHz)
• S/N: +105dB (10Hz - 20kHz)
• Cross-talk: >75dB @1KHz
• Frequency Response: 6Hz – 20 kHz +/- 0.5 dB
• Audio Latency: < 19ms
• Transmission Range 130’ (line of sight)

Kas pakuotėje?

• Wireless Transmitter
• Wireless Receiver
• Two AC Power Adapters
• Two USB cables for AC power adapter
• Two Mono RCA to Mono RCA cables
• Two Velcro
