NEBEGAMINAMA  |  Bar code: 4958043533916

Alpine R-S69.2, coaxial speakers

This is the second generation, R-Series car coaxial speaker set, which will not leave anyone indifferent with its power and performance!

  • Recommended amplifier power: 100W.
€165.00 EUR

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

.
  • Frequency band: 65 Hz - 40 kHz.
  • Sensitivity: 90 dB/W (1m).
  • Resistance: 4 ohms.

    • DESCRIPTION

    The Alpine R-Series Sound Components

    The Alpine R-Series Sound Components

    The R-Series line-up is "The Loudest Family on the Block". The products are designed to be played loud, delivering a fun and exciting listening experience and are known for dependable performance and high-quality sound. All R-Series components are developed to perfectly match each other.

    HAMR Surround
    Re-Engineered For Highest Performance

    HAMR Surround

    The High Amplitude Multi-Roll (HAMR) surround allows a maximum, linear cone excursion for high SPL, while maintaining full control over the diaphragm at any excursion stage for high sound clarity.

    Re-Engineered For Highest Performance

    More power: the 2nd generation of R-Series speakers includes many improvements over the 1st generation, such as the increased voice coil diameter from 30 to 35mm, while the Neodymium magnet diameter was also enlarged. This results in a stronger motor structure with a more powerful bass output.

    CFRP Cone
    Hi-Res Audio Tweeters

    CFRP Cone

    CFRP (Carbon Fiber Reinforced Polymer) is a very lightweight yet rigid material. On a standard, off-the-shelf speaker cone, the edges are naturally weaker than the center due to the elongated shape. Since the CFRP material is directional, it can be manipulated during the molding process to strengthen the areas of the cone that are normally weak. The result is rigidity throughout the cone that delivers accurate and efficient performance.

    Hi-Res Audio Tweeters

    The 2nd generation R-Series tweeters feature Hi-Res Audio capabilities with a frequency response of higher than 40kHz. The tweeter cones are constructed by CFRP, allowing them to reproduce very high frequencies of over 40kHz, while maintaining an overall soft and smooth tonal balance of a soft dome tweeter.

    Outstanding Clarity
    Swivel Tweeter

    Outstanding Clarity

    The new voice coil is made of aluminum, compared to regular copper wire coils. We increased the voice-coil diameter from 30mm to 35mm in the 2nd generation R-Series: the benefit is higher clarity especially in the mid-high frequency area and a more powerful bass reproduction.

    Swivel Tweeter

    Both component and coaxial models feature a ring tweeter that swivels to improve off-axis response in less-than-ideal locations. You can aim it by hand for best imaging and staging at your listening position.

    Included Mesh Grill
    Included Trim-Rings

    Included Mesh Grill

    Includes a metal mesh grill to protect the woofer in open installations.

    Included Trim-Rings

    The included installation adapters allow easy installation in a wide range of vehicles and door speaker mounts.

    TECHNICAL DATA

    SPECIFICATIONS

    Features

    Twitter

    • 1′′ (2.5cm) Ring Radiator Tweeter
    • CFRP (Carbon Fiber Reinforced Polymer) Voice Coil
    • Neodymium Magnet
    • Swivel Application
    • Hi-Res Audio Compliant

    Woofer

    • CFRP (Carbon Fiber Reinforced Polymer) Cone
    • Linear Drive Technology
    • HAMR Surround
    • Large 35mm Aluminum Voice Coil
    • Aluminum Square Wire
    • Ultra High Density Neodymium Magnet
    • DX Ring
    • Wave Guide
    • Shallow Mounting Design
    • Mounting Adapter Kit Included
    • Bi-Amp Ready Design

    Specifications

    Power Handling

    • Peak Power: 300 Watts
    • RMS Power: 100 Watts

    Dimensions

    • Woofer Mounting Diameter: 150 mm x 220 mm
    • Woofer Mounting Depth: 74 mm

    General

    • Frequency Response: 65 Hz - 40 kHz
    • Impedance: 4 Ohms
    • Sensitivity: 90 dB/W (1m)
