AMPIRE  |  Bar code: 4260052637746

AMPIRE MBM 1.24V-3G

The compact AMPIRE amplifier provides powerful and clear sound. Its versatile inputs and digital technology ensure high audio quality.

€205.63 EUR
Nebegaminama. Ši prekė nebegaminama ir nebebus papildoma. Žemiau rasite panašių prekių.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

MBM1.24V - Mono Digital Amplifier - Ultra Compact Design - Cinch & Speaker Inputs - 500 Watt RMS/1000 Watt max. - Illuminated AMPIRE Logo

Technical Data

- Mono Digital Amplifier
- Ultra-Compact Design
- Cinch & Speaker Inputs
- 500 Watt RMS/1000 Watt max.
- Illuminated AMPIRE Logo

Specification:
Power Supply
Power supply voltage: 20 - 32 VDC
Remote voltage: 8 - 28 VDC
Idling current: 0,86A
Idling current when off: 0,4mA

Amplifier Stage
Output power (RMS) @ 28,8V / 4 Ohm: 300 Watt x 1
Output power (RMS) @ 28,8V / 2 Ohm: 500 Watt x 1
Output power (max.) @ 28,8V / 4 Ohm: 600 Watt x 1
Output power (max.) @ 28,8V / 2 Ohm: 1000 Watt x 1
Distortion (THD): 0,5%
S/N Ratio: 85dB
Input sensitivity: 200mV - 6,0V

Filters
Low pass filter/slope: 30Hz - 250Hz / 12dB
Bass Boost/Frequency: 0 - 12dB / 40 - 100Hz variable

Other Functions
Fuse: 25A x 2
Max size: (LxWxH) 251 x 141 x 50mm
Weight: 1,90Kg
Inputs: RCA x2, High Level x2 (High Level Auto Turn On).
