Audison

Audison AF M4D, amplifier

€568.00 EUR

Audison AF M4D, amplifier - Ask you before buying whether we have this item in a warehouse if we do not have to be ordered and arrive within 2-21 days.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.


Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

AF add-on amplifiers are designed to supplement AF bit processor amplifiers with powerful amplifier channels.

  • Power: 4 x 260 W @ 2 Ω.
  • D-Class amplifier.
  • Hi-Res Expanded audio bandwidth up to 40 kHz.
  • Easily pairs with other Audison amplifiers.

AF companion amplifiers are designed to add powerful amplifier channels to AF bit processor amplifiers. A plug-and-play signal input harness is included to make connection to AF bit amplifiers straightforward. AF companion amplifiers are also perfect for use with systems controlled and managed by a standalone bit processor, such as a bit One HD Virtuoso. AF companions have a "straight wire" architecture, without analog preamp functions such as crossover filtering, and are intended for use with external processors. AF M4D boasts four high-fidelity amplified channels 160W x 4 @4Ω*, 260W x 4 @2Ω* with the audiophile sound of the latest generation Audison D-Class technology. Higher switching frequencies, steeper filtering, and higher-tolerance components deliver sound above and beyond the expectation of Class D – in an amazingly compact package! The audio band is extended up to 40 kHz earning the coveted High-Resolution certification. Bridging channel pairs results in 520W x 2 @4Ω*, guaranteeing flexible and powerful performance. * Output Continuous Power (RMS) @14.4 VDC, 1% THD, all channels driven.

FEATURES

  • improved audio performance and power thanks to the latest generation of ADT (Audison D-Class) technology
  • Unbeatable power/volume ratio up to 0.68 W RMS/cm³ reaching 83% of efficiency
  • Hi-Res compatibility performance, with an extended audio band up to 40 kHz
  • Maximum versatility thanks to the possibility of using the bridging option for each pair of power outputs

TECHNOLOGIES

AF LINK CABLE

Enjoy the improved audio performance of the latest generation Audison D-Class technology.

AF LINK CABLE

Maximum versatility thanks to the bridging option for each pair of channels.

AF LINK CABLE

Extended audio band up to 40 kHz.

AF LINK CABLE

Universal Speaker Simulator technology on high-level inputs for maximum compatibility with any type of Head-Unit OEM Source.


SPECIFICATIONS

AMPLIFIER TECH DATE

Channels 4
Class D-Class
Efficiency 83%
Hi Level Input Yes
Low Level Input Yes
Digital Input Well
Power supply voltage / fuse 11 ÷ 15 VDC
Operating power supply voltage 6.5 ÷ 17.5 VDC
Idling current 1.12 A
Idling current when off 0.007 mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power 47 A
Remote OUT 6.5 ÷15 VDC (150 mA)
Remote IN 4 ÷ 15 VDC (1 mA)
ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable) 1.5 VDC

AMPLIFIER STAGE

Distortion - THD @ 100 Hz, 4Ω, 70% Rated Power 0.05%
Bandwidth A (-3 dB, 2 VRMS, 4 Ω): 10 Hz to 42 kHz
S/N ratio A (A weighted @ 1 V): 103 dBA
Input sensitivity Pre-In 0.6 ÷ 6 VRMS
Input sensitivity Speaker-In 2.2 ÷ 22 VRMS
Total Power RMS 1040 W
Minimum load impedance 4Ch 2Ω
2 Ch - (Bridge) 4Ω
Output Power (RMS) @14.4 VDC, 1% THD 4Ch @ 4Ω: 160W x 4

4Ch @ 2Ω: 260W x 4

2Ch (Bridge 1/2; 3/4) @ 4Ω: 520W x 2
Adjustable Crossover Well

CEA SPECIFICATIONS

Output power @ 4Ω, 1% THD+N, 14.4 V 150W x 4
SN ratio (ref. 1W output) 80 dB

INPUTS

Input Type Pre-In / Speaker-In
Remote Sub Volume ±12dB

OTHER

Fuse 2 x 30A
Weight 2.04 kg

DIMENSIONS

Dimension A 240 mm
Dimension B 156 mm
Dimension C 47 mm


INSTRUCTIONS

User Manual (EN).
