Citronic

Citronic CSM-4 compact mixing console

Compact mixing console with 2 or 4 mono and 1 stereo line input.

€80.00 EUR 100.00 €

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

.

  • Gain: -14 to +40dB.
  • Bass EQ: ±15dB @ 80Hz.
  • Treble EQ: ±15dB @ 12kHz.
  • Phantom power supply: +48V separately switched on (only for XLR connections).

DESCRIPTION

Compact mixing console with 2 or 4 mono and 1 stereo line input. Each XLR/jack mono channel with individually switchable mic/instrument impedance level position and switchable +48V phantom power for studio condenser mics via XLR connector. The input channels have treble/bass controls, while the mono input channels have the ability to adjust digital reverb effects for both vocals and instruments. Internal player/recorder with illuminated screen, plays MP3, WMA, APE, FLAC format records from USB media, the ability to connect and play records from a mobile device via the Bluetooth interface. Output via a pair of balanced XLR connectors with very low extraneous noise levels, perfect for high-quality studio recordings or live gigs.


CSM mixers
CSM mixers
CSM mixers
CSM mixers
CSM mixers

TECHNICAL DATA

SPECIFICATIONS

  • Inputs: 2 x combo XLR/jack + stereo jack
  • Dimensions: 166 x 165 x 66mm
  • Weight: 0.89 kg
  • Power supply: 5Vdc 1A (power adapter included)
  • Maximum energy consumption: 5W
  • Gain: -14 to +40dB
  • Bass EQ: ±15dB @ 80Hz
  • Treble EQ: ±15dB @ 12kHz
  • Phantom power: +48V separately switched on (only for XLR connections)
  • Input Impedance: Microphone: 2K ohms
  • Input resistance: instrument: 1M ohm
  • Input Impedance: Linear: 20K ohms
  • Audio sources: Internal USB player/recorder and Bluetooth receiver
  • Audio formats: from USB storage: mp3, wma, ape, flac / recording mp3 (48kHz 128kB/s)
  • Bluetooth version: 2.1 + EDR
  • Frequency range: 20Hz - 20kHz (±0.5B)
  • THD +N: <0.03% @ 1kHz
  • Dynamic amplitude: 102dB
  • Signal interference: stereo: 92dB
  • Output: L + R balanced XLR
  • Output impedance: 120 ohms
  • Maximum output level: 3Vrms

Package Contents:

  • CSM series compact mixing console
  • 5Vdc power adapter
