DD Audio  |  Bar code: 0850054251671

DD Audio 312e-D4

Naujos kartos 300 serijos „e“ versija su galingu bosu ir didesniu efektyvumu. Sustiprintas konus ir nauji komponentai užtikrina išskirtinę garso kokybę

€149.00 EUR
Pristatymas per 4–8 darbo dienas

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

The all-new 300 Series “e” version introduces 10” and 12” models featuring 2.5” voice coils and 100oz motor systems. These new woofers offer increased sensitivity, Xmax, and excursion control to deliver powerful bass from more efficient enclosures using 250 to 500 Watts RMS. Updates to this series include a fiberglass-loaded non-pressed treated paper cone, taller and thicker EROM surrounds with black stitching, heavier dual-layer spiders with integrated tinsel leads, and new baskets and motor boots that improve cosmetics with DD branding.

Free Flow Cooling System
High-temp Voice Coil
Dual Layer Spider System With Integrated Tinsel Leads
Extended Pole Piece
DD Logo Basket
Double Stitched EROM Surrounds
Fiberglass Loaded Non-Pressed Cones
Embossed DDesign Magnet Boot
500W RMS

Technical Specifications

Speaker Size (In): 12
Watts RMS: 500
Watts Peak: 1500
Impedance: D4
VCD (In): 2.5
Fs (Hz): 37
Qms: 5.44
Qes: 0.73
Qts: 0.64
Vas (Liters): 22.31
BL (TM): 26
Xmech (MM): 30
Xmax (MM): 14
Frame OD (In): 15.02
Frame OD w/ Gasket (In): 12.4
Mounting Diameter (In): 13.89
Mounting Depth (In): 7.32
Motor Diameter (In): 6.69
Motor Depth (In): 2.59
Magnet Weight (Oz): 100
Woofer Displacement (CuFt): 0.1
Ported Enclosure (CuFt): 1.25 - 1.5
Shipping Weight (Lbs): 19
