DD Audio 9515K D1 ESP

INFORMACIJA

12 inch ESP subwoofer
Often imitated, but never duplicated, the 9500 has long been a staple of our subwoofer line and has been featured in many of the world’s most recognized systems. These subs easily handle 1000-2000 watts of continuous power, and bursts of up to 8000 watts. As expected, these powerhouses are loaded with a host of incredible features like EROM and V-ROM surrounds, Free Flow Motor Cooling, dual 8-layer aluminum flat wire voice coils, 28mm magnetic gaps, cast aluminum frames, non-pressed rigid cones, and our multi-layer spider system.

The 9500 Series features our Evolution Subwoofer Package (ESP). ESP units have larger diameter suspensions and deeper frames than standard subs, along with exclusive surround and cone designs. ESP subs are truly built to maximize performance in their size class.

The 9500 Series comes standard with a large dry black composite dustcap, red logo, and treated cellulose cone, but can be ordered with alternative composite dustcaps, composite cones, powder coated frames, supercharging, and a myriad of logo options to give your sub a custom look and/or additional performance for a specific application.

Specifications

-15″ subwoofer
- cast frame
- 2 x 1 ohm voicecoil
- magnet weight 31,7 kg
- 4″ voice coil diameter
- driver displacement: 9.3 liter
- recommended ported enclosure 85-170 liters ( NET )
- power handling 2500 W RMS
- peak power handling 7500 watts
- x-max: +- 22 mm
- xmech: 100 mm
- qts: 0,666
- Fs: 39,03 Hz
- Vas: 52,97 liters
- mounting depth 264 mm
- cutout diameter 386 mm.
