DD Audio DX5x7

INFORMACIJA

The Class D 5x7 component speaker set consists of high-tech, high-definition speakers designed for listeners who want to significantly exceed a standard factory upgrade.

Woofer:

Our focus on sound quality begins with precision motor assemblies. Machined magnetic gaps, driven by high-energy strontium magnets, provide strong output from a compact design. We've incorporated distortion-reducing copper shorting rings to control flux modulation and inductance. Aluminum mid-woofer cones achieve wide bandwidth and efficient energy transfer to the air. Compressed rubber surrounds are durable and optimized for light weight to increase sensitivity.

Tweeter:

The Class D component set's tweeter is our T2a 25mm ultra-light diaphragm tweeter. This new diaphragm is less than 0.003 inches thick, which is almost nothing in mm. This proprietary fabric is so thin it's practically transparent, well, it actually is transparent. The ultra-light dome is coupled to a low-distortion neodymium motor with flush/surface mounting hardware and metal grille options.

Crossover:

The 2-way crossover features low-distortion coils and metallized polypropylene caps that transmit the source without degradation. Class D components are specifically designed, enthusiast-quality sets — everything you need for excellent sound quality, and nothing you don't.

Technical data

Driver Size - in 5x7
Power Band - Watts50-150
ImpedanceS4
Frequency Response - Hz40-25kHz
dBSPL 90
Cutout Diameter - in4.96 x 7.16
Mounting Depth - in2.29
Shipping Weight - lbs8.
