DD Audio DX6x9

INFORMACIJA

The D Class coaxial speakers are high-tech, high-definition speakers designed for listeners who want to go well beyond the standard factory upgrade.

Woofer:

For the D Class speakers, our focus on sound quality started with precision motor assemblies. Machined magnet gaps driven by high-energy strontium magnets deliver strong output from a compact design. We also incorporated distortion-reducing copper shorting rings to control flux modulation and inductance. Cones are crafted from sturdy fiber with an acoustic treatment applied to the front, reducing cone cry and providing water/moisture resistance. The compressed rubber surrounds are super durable and optimized for light weight to increase sensitivity.

Tweeter:

The D Class coaxial speaker’s tweeter is our neodymium motor-driven T2 25mm ultra-light diaphragm tweeter. Its diaphragm is less than 0.003 inches thick, that’s next to nothing in mm. The proprietary dome fabric is so thin it’s practically translucent, well actually, it IS translucent. The ultra-light dome is coupled to a low distortion neodymium motor. We also used a high-tolerance Mylar capacitor for the integrated high pass filter, allowing the T2 tweeter to effortlessly output crystal clarity.

D Class coaxials are crafted with the same exotic features as esoteric separates at a price point that fits any enthusiast’s budget. Why limit yourself to OEM sound when a DD upgrade is so easy?

Technical Specs

Driver Size - in6x9
Power Band - Watts50-150
ImpedanceS4
Frequency Response - Hz40-25k
dBSPL91
Cutout Diameter - in5.96 x 8.61
Mounting Depth - in2.39
Shipping Weight - lbs8.
