DD Audio

DD Audio Redline 812d D2

The new Redline 800 Series with 4-inch voice coils delivers powerful bass and a smoother response. The improved construction ensures higher efficiency and power handling.

€812.10 EUR
Nebegaminama. Ši prekė nebegaminama ir nebebus papildoma. Žemiau rasite panašių prekių.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

Redline's new 800 Series with black 4″ Made In USA voice coils!

The completely redesigned Redline 800 Series offers a host of advantages over the older design. Redesigned frames and suspension geometry allow for a lower Fs and greater excursion potential. These two features combined give you PLENTY OF BASS, especially at lower frequencies. The revamped voice coils have increased thermal management, reduced inductance, and increased efficiency. These features give you a smoother response, more output with the same amplifiers, and greater power handling. Aesthetic improvements have also been made. The red double stitching is no more, the red line is now visible between the cone and the thermoformed multi-layer surround. The dustcap logo is made of a reflective foil layer. All cones and dustcaps now have a black matte finish. The Alucast frames feature the DD mark. The triple voice coil venting, laminated multi-spiders and extended pole pieces that made DD subwoofers so exceptional are still present in these new models. The Redline 700 Series subwoofers feature 4″ voice coils available in dual 2 or 1 ohms. Available sizes are 12″, 15″ and 18″.

Technical specifications

- 12″ subwoofer
- 4″ voice coil
- 2x 2 ohms
- power handling 3000 W RMS
- power handling 6000 W Peak
- linear x-max +- 29.4 mm
- x-mech 95 mm
- fs 33.268 Hz
- qts 0.464
- vas 24.881 liters
- sensitivity 84.3 dB/1W/1m
- mounting diameter 288 mm
- mounting depth 243 mm
- Vd 8.74 liters.
