DD Audio

DD Audio Redline 815d D2

The new Redline 800 series with Made In USA 4-inch voice coils delivers increased bass and more powerful sound. The improved construction ensures smoother response, higher efficiency, and reliable power handling.

€862.92 EUR
Nebegaminama. Ši prekė nebegaminama ir nebebus papildoma. Žemiau rasite panašių prekių.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

Redline's new 800 Series with black 4″ Made In USA voice coils!

The completely redesigned Redline 800 Series offers numerous advantages over the older design. The redesigned frames and suspension geometry allow for a lower Fs and greater excursion potential. These two features combined give you PLENTY OF BASS, especially at lower frequencies. The revised voice coils have increased thermal management, reduced inductance, and increased efficiency. These features give you a smoother response, more output with the same amplifiers, and greater power handling. Aesthetic improvements have also been made. The red double stitching is gone, the red line is now visible between the cone and the thermoformed multi-layer surround. The dust cap logo is made of a reflective foil layer. All cones and dust caps now have a black matte finish. The Alucast frames feature the DD logo. The triple voice coil ventilation, laminated multi-spiders, and extended pole pieces that made DD subwoofers so exceptional are still present in these new models. Redline 700 series subwoofers feature 4″ voice coils, available in dual 2 or 1 ohms. Available sizes are 12″, 15″, and 18″.

Technical data

- 15″ subwoofer
- 4″ voice coil
- 2x 2 ohms
- power handling 3000 W RMS
- power handling 6000 W Peak
- linear x-max +- 29.4 mm
- x-mech 95 mm
- fs 30.973 Hz
- qts 0.483
- vas 61.639 liters
- sensitivity 87.1 dB/1W/1m
- mounting diameter 350 mm
- mounting depth 255 mm
- Vd 10.71 liters.
