DD Audio  |  Bar code: 0850013938643

DD Audio RL-SW12-D2

REDLINE SW series subwoofers provide extreme bass and are perfect for sealed and vented enclosures. These speakers feature high-quality characteristics for everyday use.

€81.63 EUR
Nebegaminama. Ši prekė nebegaminama ir nebebus papildoma. Žemiau rasite panašių prekių.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

REDLINE SW Series subwoofers offer extreme bass and value. These Hi Def Tuned subwoofers perform great in sealed and small vented enclosures at low to moderate power levels. They feature all the performance characteristics needed for daily use and are available in two impedance options to match them to any DD Audio amplifier.

High Temp 2” Voice Coil
DVC 2 Ohm, DVC 4 Ohm
EROM Surround
Vented Stamped Steel Frame
Vented Back Plate
Push Terminals

Specifications

Speaker Size (In):12
Watts RMS:100 - 300
Watts Peak:600
Impedance:D2 / D4
VCD (In):2
Piston Diameter (In):10
Fs (Hz):33
Qms:8.673
Qes:0.54
Qts:0.508
Vas:65.339
dBSPL:89
Xmech (MM):25
Xmax (MM):8
Frame OD (In):12.22
Frame OD w/Gasket (In):12.4
Mounting Diameter (In):11
Mounting Depth (In):5.34
Motor Diameter (In):5.27
Motor Depth (In):1.7
Magnet Weight (Oz):55
Woofer Displacement (CuFt):0.05
Sealed Enclosure (CuFt):0.8 - 1.5
Ported Enclosure (CuFt):1.0 - 1.75.
