Emphaser, EA-S4 4-channel car audio amplifier, 4x70W

Emphaser EA-S4 – 4-Channel Class AB AmplifierEmphaser EA-S4 is a high-quality 4-channel Class AB car amplifier designed to deliver exceptional sound quality and powerful performance in your vehicle.
€187.00 EUR

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

Emphaser EA-S4 – 4-Channel Class AB Amplifier

Emphaser EA-S4 is a high-quality 4-channel Class AB car amplifier designed to deliver exceptional sound quality and powerful performance in your vehicle. This amplifier features a high signal-to-noise ratio, wide frequency response, and a robust aluminum housing for efficient cooling.

Technical Specifications:

  • Output Power: 4 &times; 70 W RMS @ 4 &Omega; (<1 % THD / 13.8 V)
  • 4 &times; 110 W RMS @ 2 &Omega; (<1 % THD / 13.8 V)
  • Bridged Mode: 2 &times; 220 W RMS @ 4 &Omega; (<1 % THD / 13.8 V)
  • Frequency Response: 10 Hz – 60 kHz
  • Crossover Filters: HPF 50–500 Hz and LPF 50–500 Hz, 12 dB/oct., switchable
  • Input Sensitivity: 1 – 4.8 V
  • Signal-to-Noise Ratio (S/N): > 100 dB
  • Damping Factor: > 200 @ 4 &Omega;
  • Dimensions: 320 &times; 52 &times; 129 mm (L &times; H &times; W)
  • Housing: Die-cast aluminum power and speaker connection terminals

Key Advantages:

  • Powerful Performance: ensures clear and dynamic sound reproduction even under higher loads.
  • Wide Frequency Response: allows precise reproduction of both low and high frequencies.
  • Flexible Crossover Control: HPF and LPF filters with the option to switch off provide the ability to customize sound to individual needs.
  • Reliable Connectivity: high-quality RCA and high-level inputs ensure a stable and reliable connection with other audio system components.
  • Efficient Cooling: the aluminum housing ensures optimal heat management and longevity.

The Emphaser EA-S4 is an excellent choice for those seeking high-quality sound in their car, regardless of whether you are using an OEM or aftermarket radio.
