Ground Zero  |  Bar code: 4037072024579

Ground Zero GZNK 165SQ-K

6.
€399.00 EUR

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

5″ high-end midwoofer with GZ design cast aluminum basket offering unique ventilation

- 5″ SQ midwoofer
- 38 mm / 1.5″ voice coil
- High-tech Kevlar® cone
- Impedance linear copper cap
- Cast aluminum
- GZ design cast aluminum basket
- GZ design hexagon style NRG protection grille with logo option
- Gold-plated screw and solder terminals
- 1 pair / pack

Technical data

Speaker type: 165 mm / 5” SQ midwoofer
Impedance (nominal): 4 ohms
Frequency response: 40 Hz – 5 kHz
Basket: Aluminum cast
Cone: Kevlar
Motor: Neodymium-ferrite hybrid system
Voice coil: 38 mm / 1.5“ CCA
Power handling: (RMS) 130 Watts (12dB/oct HPF@ 60 Hz)
Power handling: (max.) 190 Watts (12dB/oct HPF@ 60 Hz)

Technical Parameters (TSP)
Resonance frequency: 43 Hz
Efficiency: (SPL) 88 dB
Re: 3.3 ohms
Qms: 4.57
Qes: 0.53
Qts: 0.48
Vas: 24.13 L / 0.82 cu.ft.
Mms: 14.3 g
BL: 4.85 N/A
Rms: 0.84 kg/s
Cms: 0.98 mm/N
LE: 0.18 mH
Xmax: (excursion) 12 mm / 0.47“ (peak-peak)
