HELIX P ONE MK2
Raw power – total control
Plenty of power and enormous stability: Our new P ONE MK2 is the ideal performance package for any subwoofer configuration. With up to 1,800 Watts RMS @ 1 Ohm, the upgrade to our powerful mono amplifier will drive any woofer, always maintaining full control due to its enormous damping factor.

High-res audio and an all-digital signal chain
The P ONE MK2 isn't just designed for driving subwoofers. With an ultra-wide frequency range of up to 40 kHz and an excellent signal-to-noise ratio, as well as an extremely low THD, you can expect nothing less than high-res audio quality, making it ideal for use as a full-range amplifier.
Thanks to the newly integrated optical digital input, interference-free and ground-isolated signal transmission in the best quality is now possible right up to the amplifier. The input accepts signals up to a sampling rate of 96 kHz loss-free via fiber optics and converts them back into an analog level via an advanced 32-Bit BurrBrown D/A converter. Thus, the P ONE MK2 can be perfectly combined with one of our DSP amplifiers with optical digital output, such as the HELIX P SIX DSP ULTIMATE.

Extremely high power density with ultra-compact dimensions
When it comes to power density, the P ONE MK2 plays in a league of its own. No other HELIX amplifier packs as much power into such a compact package. This unique power-to-size ratio is achieved by our tremendously efficient Class D concept, which goes hand in hand with exceptionally low heat dissipation.

Features
High-end Class D mono amplifier with up to 1,800 Watts RMS @ 1 Ohm – perfect for all 2 x 2 Ohm subwoofers connected in parallel
High-Res Audio capability thanks to an extended audio frequency response of over 40 kHz for incredible sound quality
Extremely high efficiency and low heat dissipation with minimal dimensions
High damping factor

Technical data

Power RMS ≤ 1% THD+N
- @ 4 Ohms 1 x 500 Watts
- @ 2 Ohms 1 x 880 Watts
- @ 1 Ohm 1 x 1,500 Watts
- bridged @ 4 Ohms -
- bridged @ 2 Ohms -
Max. output power per channel* Up to 1.800 Watts RMS @ 1 Ohms
Amplifier technology Class D
Inputs 2 x RCA / Cinch
1 x Remote In
1 x Optical SPDIF (28 - 96 kHz)
Input sensitivity RCA / Cinch 0.5 - 8 Volts
Input impedance RCA / Cinch 20 kOhms
Input impedance highlevel -
Outputs 1 x Speaker output
Output voltage RCA / Cinch -
Signal converter for digital input BurrBrown 32 Bit DA converter
Frequency response 21 Hz - 40,000 Hz
Bass boost -
Highpass -
Lowpass -
Bandpass -
Subsonic 21 Hz
Phase -
Slope high- / lowpass -
Slope subsonic / lowpass Butterworth 48 dB/Oct.
Signal-to-noise ratio digital input 110 dB (A-weighted)
Signal-to-noise ratio analog input 110 dB (A-weighted)
Distortion (THD) 0.01 %
Damping factor 450
Operating voltage 10.5 - 17 Volts (max. 5 sec. down to 6 Volts)
Idle current 1500 mA
Fuse 4 x 30 A LP-Mini-fuse (APS)
Power rating DC 12 V ⎓ 160 A max.
Additional features Input mode switch, SPDIF Direct In switch, Start-Stop capability
Dimensions (H x W x D) 50 x 260 x 190 mm /
1.97 x 10.24 x 7.48”
