Monitor Audio IA750-4, home theater amplifier

The A750-4 delivers an incredible four channels of 750W of power and is the perfect amplifier for the most demanding large home theater setups.

€4,000.00 EUR

Monitor Audio IA750-4, home theater amplifier - Ask you before buying whether we have this item in a warehouse if we do not have to be ordered and arrive within 2-21 days.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

.

  • Power: 4 x 750 W
  • Class D amplifier ensures high performance.
  • Fully customizable DSP amplifier with online configurator.


DESCRIPTION

In a larger installation where pure power is required, the Monitor Audio IA750-4 is the ideal choice. A 2U full width high-power amplifier, it features full DSP matrix configuration and is simple to install and use. But power is its trump card: four channels of 750 W each deliver the most impressive home theater sound imaginable. It's capable of getting the very best out of any system and is the perfect partner for Monitor Audio's THX Ultra certified Cinergy home theater system.

TECHNICAL DATA

SPECIFICATIONS

Channels

4

Output Power @ 2 Ohms

4 x 750W SE

Output Power @ 4 Ohm​

4 x 750W SE, 2 x 1500W BTL

Output Power @ 8 Ohm​

2 x 400W SE, 2 x 1500W BTL

Output Power @ 70V ​

2 x 1200W BTL

Output Power @ 100V

2 x 1500W BTL

Maximum Total Output Power, all channels driven

3000 W

Power Consumption

700 W

Thermal Output

2400 BTU

Polarity (Default)

Non-inverting

Dimensions

88 x 440 x 329 mm (3 6/16 x 17 5/16 x 12 15/16 ”)

Output Voltage

80Vp / 160Vpp (SE unloaded), 160Vp / 320Vpp (BTL unloaded)

Signal to Noise Ratio

>108dB (A-weighted, 20Hz – 20kHz, 8 Ohm load)

THD+N (typical).

<0.05% (20 Hz – 20 kHz, 8 Ohm load, 3db below rated power)​

Frequency Response

+0/-0.25dB 20Hz – 20kHz (8 Ohm load, 3dB below rated power

Protection Circuits​

Short circuit -, DC, Undervoltage -, Temperature - and Overload protection​

Power Supply​

Switch mode power supply with Power Factor Correction (PFC) and standby converter

Operating​ Voltage/Frequency

Universal Mains, 100 V - 240 V, 50 Hz - 60 Hz

Standby Consumption​

<0.5W

Accessories

Rack mount kit (pre-installed)

Power Ratings​

1% THD @ 120Vac and 230Vac

Cabinet Finish

Black Anodized

DOCUMENTS

INSTRUCTIONS

User Manual (EN).
