Monitor Audio Radio One. central speaker (various colors)

€780.00 EUR

Color

Product variants

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA
DESCRIPTION
TECHNICAL DATA
DOCUMENTS

INFORMACIJA

Radius series central speaker from Monitor Audio with an exclusive design and high-quality sound. A column that will not leave you indifferent with its ergonomics and features!

Power: 100W.
Frequency band: 90 Hz — 35 kHz.
Sensitivity: 87 dB.
Resistance: 6 ohms.

DESCRIPTION

This product is now available to use with home theater design software, The CEDIA Designer. Read more .

Technology

4" C-CAM bass driver - Radius features all new bass drivers with concave cone profiles, introduced by our top-of-the-range Platinum speakers and applied subsequently to Gold GX. Extensive research and FEA modeling have allowed us to perfect the relationship between the new radiating diaphragm and its motor design, introducing larger motor sizes and voice coils for increased excursion, higher power capability and reduced distortion.
C-CAM Gold Dome tweeter - optimized to deliver the finest and widest performance within the compact Radius cabinets. It benefits from a more efficient rear-venting design, releasing air trapped and compressed at the back of the tweeter dome, and guiding it around the drive assembly to a rear-loading chamber.
Single through-bolt driver fixing provides mechanical de-coupling and enhanced mid-band clarity and resolution. The through-bolts also act as rigid cross bracing to give a very solid non-resonant cabinet.
Wall mounting bracket Included

TECHNICAL DATA

SPECIFICATIONS

Frequency Response

90 Hz — 35 kHz

Sensitivity (1W@1M)

87 dB

Nominal Impedance

6 ohms

Power Handling (RMS)

75 W

System Power Handling (RMS)

100W

Recommended Amplifier Requirements

30 — 100 W

Maximum SPL

106 dBa

Bass Alignment

C:Bass reflex - Front ported L/R:Bass reflex - Side ported

Drive Unit Complement

3 x 4" (100mm) C-CAM cone bass/mid driver
3 x 1" (25mm) C-CAM Gold Dome tweeter

Cabinet Dimensions (H x W x D)

175 x 980 x 67 mm (6 ^7/8 x 38 ^9/16 x 2 ^5/8 ")

Cabinet Dimensions (Including Grille and Terminals (H x W x D))

175 x 980 x 79 mm (6 ^7/8 x 38 ^9/16 x 3 ^1/8 ")

Cabinet Dimensions (Including Grille and Bracket (H x W x D))

175 x 980 x 84 mm (6 ^7/8 x 38 ^9/16 x 3 ^5/16 ")

Pre-Construction Bracket

Dedicated bracket included

Weight

7.4 kg (16 lb 4 oz)

Sold As

Single Unit

DOCUMENTS

INSTRUCTIONS

User Manual (EN).
