Phoenix Gold ZP12D2 – 12" StreetBass Subwoofer (1500W RMS / 4500W MAX)

Phoenix Gold ZP12D2 is a high-end 12-inch StreetBass subwoofer, designed for extreme sound pressure (SPL) and deep, controlled bass. This model belongs to the ZP series, which focuses on maximum reliability, high power handling, and precise low-frequency reproduction in car audio systems.

Thanks to its 3" (75 mm) OFC voice coil, reinforced dual magnetic system, and precision-engineered suspension, the ZP12D2 is capable of operating in extreme conditions while maintaining high sound quality even under maximum load.

This model is ideal for SPL projects, "street bass" systems, and high-power bass installations where maximum pressure and control are required.

Key Features

• 1500W RMS / 4500W MAX: ultra-high power for SPL systems
• 3" OFC voice coil: high thermal resistance and stability
• Dual magnet: powerful motor for maximum level of control
• Optimized suspension: high excursion (XMAX) and precise movement
• Non-pressed paper cone: natural sound and good damping
• Triple poly-cotton spider: durability and precision
• Ventilated construction: efficient cooling under high loads
• Designed for SPL and StreetBass: for maximum sound power

Technical Specifications

• Type: 12" StreetBass subwoofer
• Power (RMS): 1500W
• Power (MAX): 4500W
• Impedance: 2 x 2 Ohm (Dual Voice Coil)
• Voice coil: 3" (75 mm) OFC
• Sensitivity: ~83 dB (1W/1m)
• Frequency response: ~25 Hz – 300 Hz
• Fs: ~32.7 Hz
• Qts: ~0.56
• Vas: ~24 L
• Mounting depth: ~186 mm
• Recommended enclosure: 45–60 L (bass reflex) / 20–35 L (sealed)

Construction and Technologies

The Phoenix Gold ZP12D2 is built using high-quality components designed for extreme SPL use. The dual ferrite magnet ensures a strong magnetic field, while the 3" OFC coil allows for stable performance even under long-term load.

A specially designed suspension system with triple poly-cotton layers ensures precise cone movement and high linear excursion, allowing for maximum low-frequency pressure.

Application

This subwoofer is perfect for:

• SPL competitions
• StreetBass systems
• Extreme car audio projects
• High-power bass installations

Why choose Phoenix Gold?

Phoenix Gold is a world-renowned car audio manufacturer known for high-quality SPL and Hi-Fi solutions. The ZP series is designed for those who want maximum power, reliability, and professional-grade sound.
