Phoenix Gold ZP12D4 – 12" StreetBass Subwoofer (1500W RMS / 4500W MAX, D4)

Phoenix Gold ZP12D4 is a high-end 12-inch StreetBass subwoofer, designed for extreme low-frequency reproduction and high sound pressure levels (SPL). This model belongs to the ZP series, which is focused on maximum reliability, robust construction, and powerful, controlled bass in car audio systems.

With 1500W RMS and up to 4500W MAX power, the ZP12D4 is built to operate under extreme loads while maintaining precise and dynamic low-frequency reproduction. It is an ideal choice for SPL projects and "street bass" systems.

Key Features

• 1500W RMS / 4500W MAX: ultra-high power for professional systems
• 3" (75 mm) OFC voice coil: resistant to high temperatures and heavy loads
• Dual ferrite magnet: high control accuracy and force
• D4 (2x4 Ohm) configuration: flexible wiring for various systems
• Non-pressed paper cone: natural sound and good damping
• Triple poly-cotton spider: stable and precise movement
• High XMAX excursion: maximum low-frequency pressure
• Vented design: efficient cooling for intensive use

Technical Specifications

• Type: 12" StreetBass subwoofer
• Power (RMS): 1500W
• Power (MAX): 4500W
• Impedance: 2 x 4 Ohm (Dual Voice Coil)
• Voice coil: 3" (75 mm) OFC
• Sensitivity: ~84.9 dB (1W/1m)
• Frequency range: ~25 Hz – 300 Hz
• Fs: ~36.3 Hz
• Qts: ~0.48
• BL: ~27.5 Tm
• Sd: ~530 cm²
• Mounting depth: ~186.5 mm
• Mounting diameter: ~281.5 mm
• Weight: ~11.6 kg

Design and Technology

Phoenix Gold ZP12D4 is built using high-quality components designed for long-term SPL use. The dual ferrite magnet and precisely calculated magnetic gap ensure high efficiency and precise cone control even under extreme loads.

The subwoofer's construction features a 3" OFC voice coil, which allows it to withstand high temperatures, while the reinforced suspension system ensures long excursion and stable low-frequency reproduction.

Application

This subwoofer is ideal for:

• SPL competitions
• StreetBass systems
• Powerful low-frequency installations
• Professional car audio projects

Why choose Phoenix Gold?

Phoenix Gold is a high-end car audio manufacturer known for reliable and powerful solutions. The ZP series is designed for enthusiasts and professionals who strive for maximum sound power, precision, and reliability.

More information about the product can be found on the official manufacturer's page:
Phoenix Gold ZP12D4 – official page
