Pioneer GM-DX104

INFORMACIJA

The engineered high-quality operational amplifiers in the GM-DX104 reduce noise in low-signal circuits to produce crystal-clear tones across a wide band.

This compact amplifier also offers the flexibility to power 4, 3, or 2 speakers, whether bridged or unbridged, resulting in 4x 45 watts RMS at 4 ohms or 90 watts RMS when bridged.

Its compact, energy-efficient design and high-voltage compatibility ensure easy installation in virtually any vehicle, making it the ultimate choice for audiophiles seeking exceptional performance and versatility.

Engineered to be compatible with high-voltage systems up to 16V, the GM-DX104 is an ideal solution for electric vehicles (EVs) and other advanced applications. Its low current consumption, averaging only...

Specifications

Bridgable:
Yes

Class:
D

Grounding System:
Negative

Power Source:
14.4 V DC (10.5 V to 16.0 V)

Protection Control system:
Yes

Terminal Type:
Removable

Unit Weight:
1.2 lbs

Allowable Load Impedance:
2 ohm to 8 ohm allowable

Avg Current Consumption (amps x #ch):
1.6 A (4 Ohms x 4ch),1.6 A (2 Ohms x 4ch),1.6 A (4 Ohms x 2ch Bridged)

Continuous-Power-Output:
45 W x 4-Channel - 4 Ohm, 90 W x 2-Channel - 4 Ohm Bridged

Frequency Response Channel:
10Hz to 40kHz (+0dB,-3dB) A/B Ch

Fuse Rating:
15 A

High-Pass Crossover frequency:
80 Hz (LPF/OFF/HPF)

High-Pass Slope (dB/octave):
-12 dB/oct

Low-Pass Crossover frequency:
80 Hz (LPF/OFF/HPF)

Low-Pass Slope (dB/octave):
-12dB/oct

Maximum Power Output:
100 W x 4-Channel (4 Ohm),200 W x 2-Channel (4 Ohm Bridged)

RCA Inputs:
4-Channel

Signal to Noise:
93 dB

Speaker Line input Sensor:
Yes
