Roksan VINYL SYSTEM CONTROL (VSC / VSC2), external power supply (various colors)

External power supply for the Roksan Xerxes 20 Plus record player with a built-in high-level correction amplifier for MM and MC type heads.
€4,400.00 EUR

Roksan VINYL SYSTEM CONTROL (VSC / VSC2), external power supply (various colors) - White color - Ask you before buying whether we have this item in a warehouse if we do not have to be ordered and arrive within 2-21 days.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

.

  • Changing the rotation speed at the touch of a button
  • Three switchable gain levels
  • High quality details

DESCRIPTION

For ultimate convenience and a fully comprehensive solution for getting the best performance from your Xerxes Turntable , the VSC and VSC2 units combine both an RPM speed control and RPP phono stage in a single chassis.

The VSC also powers the Xerxes Turntable, it has one reference DS1.5 linear power supply for both RPM and RPP sections and the VSC2 has two DS1.5 power supplies, one dedicated to each section.

(The VSC can be upgraded to VSC2 specification as an after-purchase option)

Key Features

  • Available in two versions: VSC with a single DS1.5 PSU module or VSC2 with twin DS1.5 PSU modules
  • Ultimate control and convenience for the Xerxes Turntable in one box
  • Combines reference MM/MC phono stage with reference speed control
  • VSC is upgradeable to VSC S2

TECHNICAL DATA

SPECIFICATIONS

Power Supply

VSC — DS1.5 x 1
VSC2 — DS1.5 x 2

Output Voltage (RPM)

16 V RMS (33 and 45 RPM)

Phase (RPM)

0 degrees and 90 degrees

DC Offset (RPM)

<10 mV

Harmonic Distortion (RPM)

<0.1%

Output Impedance (RPM)

<0.1 ohms

Gain Settings (RPP)

MM: 40.6dB @ 1kHz
MC1: 56dB @ 1kHz
MC2: 65.5dB @ 1kHz

Signal to Noise Ratio (RPP)

MM: >89dB (ref. 5.0 mV)
MC1: >79dB (ref. 5.0mV)
MC2: >70 dB (ref. 5.0 mV)

Harmonic Distortion (RPP)

<0.01%

Overload Margin (RPP)

26 dB all settings

Output Impedance (RPP)

< 50 ohms

DOCUMENTS

INSTRUCTIONS

User Manual (EN).
