Rotel

Rotel A12MKII, integrated audio amplifier (various colors)

The A12MKII integrated amplifier stands out with its slim, elegant design profile, designed and tailored for music fans.
Regular price €1,199.00 EUR

Rotel A12MKII, integrated audio amplifier (various colors) - Black - Ask you before buying whether we have this item in a warehouse if we do not have to be ordered and arrive within 2-21 days.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.


Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

.

  • Power: 2 x 60W.
  • Class AB amplifier.
  • DAC: Texas Instruments premium 32-bit/384kHz.
  • Moving Magnet Phono input for turntables.

DESCRIPTION

The A12MKII Integrated Amplifier stands well above its slim, sleek design profile designed and engineered for music lovers.

Powered by Rotel's oversized in-house manufactured toroidal transformer the A12MKII delivers 60 Watts of clean, dynamic Class AB output power into 8 ohms.

A Moving Magnet Phono Stage, 4 RCA analog, 4 digital, PC-USB and high quality wireless aptX TM Bluetooth input ensures connection to your favorite sources.

The premium 32-bit Texas Instruments DAC extracts genuine and accurate details of the music with optimized circuits preserving the integrity of the audio stream.

Slim and powerful, the A12MKII delivers on Rotel's iconic brand heritage.

TECHNICAL DATA

SPECIFICATIONS


Engineered with care.

Rotel A12MKII, integrated audio amplifier (various colors)

DIMENSIONS (W × H × D)
430 × 93 × 345mm
17" × 3.6" × 13.5"
FRONT PANEL HEIGHT
80mm (3.15")
POWER REQUIREMENTS
120V, 60Hz
POWER CONSUMPTION
230W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
8.76kg (19.31lbs.)
BTU RATING (4Ω, 1/8th power)
632 BTU/h

Rotel A12MKII, integruotas garso stiprintuvas (įvairių spalvų)

MAXIMUM POWER OUTPUT
120W/Ch (4Ω)
CONTINUOUS POWER OUTPUT
60W/Ch (8Ω)
TOTAL HARMONIC DISTORTION (THD)
<0.018%
FREQUENCY RESPONSE
Line Level Inputs: 10Hz - 100kHz, 0±0.5dB
Digital Inputs: 10Hz - 90kHz, 0±2dB
Phono Input: 20Hz - 20kHz, 0±0.5dB
S/N WHEEL (IHF "A" Weighted)
Line Level Inputs: 100dB
Digital Inputs: 103dB
Phono Input: 90dB

INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)
<0.03%
DAMPING FACTOR
220
INPUT SENSITIVITY
Line Level Inputs: 230mV
Digital Inputs: 0dBfs
Phono Input (MM): 3.4mV
INPUT IMPEDANCE
Line Level Inputs: 24kΩ
Digital Inputs: 75Ω
Phono Input (MM): 47kΩ
INPUT OVERLOAD
Line Level Inputs: 4V
Phono Input: 50mV
PREOUT LEVEL
1.2V
OUTPUT IMPEDANCE
470Ω
TONE CONTROLS
±10dB at 100Hz / 10kHz
DIGITAL INPUT
SPDIF LPCM (Up to 24-bit/192kHz)
PC-USB
USB Audio Class 1 (up to 24-bit/96kHz)
USB Audio Class 2 (up to 32-bit/384kHz)*
*Driver installation required
Roon Tested

DOCUMENTS

INSTRUCTIONS

User Manual (EN).
