SounDigital  |  Bar code: 7898644527150

SounDigital 800.1 EVO5 2 Ohm

Compact and modern amplifier, delivering 800W of power. Enjoy cleaner and truer sound with patented technologies.

€159.00 EUR
Pristatymas per 4–8 darbo dienas

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

The 800.1 EVO 5 is a compact, modern amplifier that delivers 800W RMS of power, distributed through 1 channel.

The amplifier features exclusive and patented technologies that ensure a cleaner and more realistic sound experience, while also providing improved performance and efficiency for the most ambitious projects.

Technical specifications

Power @ 2Ω: 800W
Power @ 4Ω: 528W
Power @ 8Ω: 348W

Frequency Response:

10Hz ~ 20kHz

Subsonic Filter (HP 12dB/8º):

10Hz ~ 80Hz

Low Pass Filter (LP 12dB/8º):

50Hz ~ 20kHz

Operating Voltage:

8V ~ 16V

SNR:

2Ω: 96dB
4Ω: 97dB

Input Sensitivity (RCA): 0.2V ~ 4V

Input Sensitivity (High Level input): 1.5V ~ 15V

Current Draw (Music): 2Ω: 40A

Current Draw With Resistive Load (1kHz @ 12.6V): 2Ω: 81A

Total Efficiency: 2Ω: 79%

Damping Factor (@100Hz Rated Impedance): 200

Power Cable: 10mm² (7AWG)

Audio Output Cable: 2 x 2mm² (12 AWG)

Recommended Fuse (Music): 40A

Recommended Battery (Music): 60Ah

Width: 4.4 in / 11,3 cm

Length: 5.8 in / 14,8 cm

Height: 2 in / 5,1 cm

Weight: 1.54 lb / 0,7 Kg
