SounDigital

SounDigital 800.4 EVO 6 - 4 Ohm

A powerful amplifier from Brazil, recognized for its intense and loud sound. Designed for those who enjoy strong music, it provides an exceptional audio experience.

€202.26 EUR
Nebegaminama. Ši prekė nebegaminama ir nebebus papildoma. Žemiau rasite panašių prekių.

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

The Soundigital Evolution series will change the game for anyone who loves to play loud and intense. These amplifiers have quickly earned a lot of respect and become some of the biggest from Brazil. And it’s no wonder they are made in Brazil in their own factory, the design team responsible for Soundigital has some very well-known names competing in Pancadao, a sport where you play loud with the help of speaker walls, like homes.

Technical specifications

POWER RATING
12,6V: @ 2Ω: 4 x 200 W RMS
12,6V: @ 4Ω: 4 x 132 W RMS
12,6V: @ 4Ω 2 x 400 W RMS ( Bridge )
14,4V: @ 2Ω: 4 x 225 W RMS
14,4V: @ 4Ω: 4 x 140 W RMS

Frequency Response (-3dB): 5Hz ~ 20kHz

Low Pass Filter (12dB/octave): 80Hz

High Pass Filter (12dB/octave): 80Hz

Operating Voltage: 9V ~ 16V

SNR: 93dB

Input Sensitivity (RCA): 0.2V ~ 2V

Current Draw (music): 39A

Current Draw (max.): 78.7A

Total Efficiency: 80%

Damping Factor (@100Hz nominal impedance): 200

Power Cable: 10mm² (7 AWG)

Speaker Cable: 2 x 2.5mm² (13 AWG)

Recommended Fuse (music): 40A

Recommended Battery (minimum): 60Ah

Width: 4.4″ / 11.2 cm

Length: 4.2″ / 10.7 cm

Height: 2.0″ / 5.2 cm

Weight: 0,609 kg / 1.342 lb


Älä kytke vahvistinta alle nimelliskuorman!

Do not run your amp under rated impedance!.
