SounDigital 800.5 EVO 6 - 4 Ohm
SounDigital 800.5 EVO 6 - 4 Ohm - Ask you before buying whether we have this item in a warehouse if we do not have to be ordered and arrive within 2-21 days.
▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.
Free delivery in Lithuania from € 100
Free delivery in Lithuania from € 100
In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.
Pick up the goods in the store for € 0
Pick up the goods in the store for € 0
Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00
INFORMACIJA
It's not just about sound.
It's a feeling, a technology, and an emotion. THIS IS EVO6.
It's not just another amplifier; it's a leap in automotive audio evolution.
It re-engineers amplifier design. Every detail has been redesigned to deliver superior sound quality, making your musical experience much more immersive.
Introducing the new 800.5 EVO6. With the help of AI, we've achieved unprecedented miniaturization, creating the world's smallest amplifiers that break power density records.
High efficiency that fits anywhere.
Join us on a journey to the future.
Technical specifications
Power @ 4Ω: 4 x 100W RMS
Power @ 8Ω: 4 x 66W RMS
SUBWOOFER: 4Ω: 1 x 400W
Bridge Power @ 8Ω: 2 X 200W RMS
SUBWOOFER: 8Ω: N/A
Frequency Response (-3dB): 80Hz ~ 25kHz
SUBWOOFER: 5Hz ~ 80Hz
Low Pass Filter (12dB/octave): 80Hz
High Pass Filter (12dB/octave): 80Hz
Operating Voltage: 9V ~ 16V
SNR: 103.88dB
SUBWOOFER: 102dB
Input Sensitivity (RCA): 0.2V ~ 2V
Current Draw (music): 39A
Current Draw (max.): 78.7A
Total Efficiency: 80%
Damping Factor (@100Hz nominal impedance): 200
Power Cable: 10mm² (7 AWG)
Speaker Cable: 1.5mm² (15 AWG) / 2.5mm² (13 AWG)
Recommended Fuse (music): 40A
Recommended Battery (minimum): 60Ah
Width: 6.01″ / 15.7 cm
Length: 4.52″ / 11.7 cm
Height: 2.07″ / 5.5 cm
Weight: 0.74 kg / 1.63 lb
Älä kytke vahvistinta alle nimelliskuorman!
Do not run your amp under rated impedance!.
