SounDigital  |  Bar code: 7898644529345

SounDigital 800.5 EVO 6 - 4 Ohm

Experience the new evolution of car audio with SounDigital EVO6. This compact amplifier has been redesigned for excellent sound quality and an immersive musical experience.

€299.00 EUR
Pristatymas per 4–8 darbo dienas

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

It's not just about sound.

It's a feeling, a technology, and an emotion. THIS IS EVO6.
It's not just another amplifier; it's a leap in automotive audio evolution.

It re-engineers amplifier design. Every detail has been redesigned to deliver superior sound quality, making your musical experience much more immersive.

Introducing the new 800.5 EVO6. With the help of AI, we've achieved unprecedented miniaturization, creating the world's smallest amplifiers that break power density records.

High efficiency that fits anywhere.
Join us on a journey to the future.

Technical specifications

Power @ 4Ω: 4 x 100W RMS
Power @ 8Ω: 4 x 66W RMS
SUBWOOFER: 4Ω: 1 x 400W

Bridge Power @ 8Ω: 2 X 200W RMS
SUBWOOFER: 8Ω: N/A

Frequency Response (-3dB): 80Hz ~ 25kHz
SUBWOOFER: 5Hz ~ 80Hz

Low Pass Filter (12dB/octave): 80Hz

High Pass Filter (12dB/octave): 80Hz

Operating Voltage: 9V ~ 16V

SNR: 103.88dB
SUBWOOFER: 102dB

Input Sensitivity (RCA): 0.2V ~ 2V

Current Draw (music): 39A

Current Draw (max.): 78.7A

Total Efficiency: 80%

Damping Factor (@100Hz nominal impedance): 200

Power Cable: 10mm² (7 AWG)

Speaker Cable: 1.5mm² (15 AWG) / 2.5mm² (13 AWG)

Recommended Fuse (music): 40A

Recommended Battery (minimum): 60Ah

Width: 6.01″ / 15.7 cm

Length: 4.52″ / 11.7 cm

Height: 2.07″ / 5.5 cm

Weight: 0.74 kg / 1.63 lb


Älä kytke vahvistinta alle nimelliskuorman!

Do not run your amp under rated impedance!.
