SounDigital  |  Bar code: 7898644525385

SounDigital SD2000.2 EVO 5.0 - 4 ohm

Compact and modern, this amplifier delivers a clean and true sound, perfect for the most ambitious audio projects. Its exclusive technologies ensure enhanced performance and efficiency.

€399.00 EUR
Pristatymas per 4–8 darbo dienas

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

INFORMACIJA

The 2000.4 EVO 5 is a compact, modern amplifier that delivers 2000W RMS of power distributed across 4 channels. The amplifier features exclusive and patented technologies that make the sound experience cleaner and truer, while also ensuring better performance and efficiency for the most ambitious projects.

Technical Data

Power @ 1Ω: N/A
Power @ 2Ω: 2 X 1000W

Bridge Power @ 2Ω: N/A
Bridge Power @ 4Ω: 1 X 1200W

Frequency Response (-3dB):

10Hz ~ 20kHz

Low Pass Filter (LP -12dB/8):

80Hz

High Pass Filter (HP -12dB/8):

80Hz

Operating Voltage:

8V ~ 16V

SNR:

90dB

Input Sensitivity:

0.2 ~ 4V

Current Draw (Music):

2Ω: 89A
4Ω: 88A

Current Draw With Resistive Load (1kHz @ 12.6V):

2Ω: 178A
4Ω: 176A

Total Efficiency:

2Ω: 89%
4Ω: 90%

Damping Factor (@100Hz Rated Impedance):

200

Minimum Audio Output Impedance:

2Ω: 1 ohm
4Ω: 2 ohms

Minimum Bridge Impedance:

2Ω: 2 ohm
4Ω: 4 ohms

Recommended Fuse (Music):

100A

Recommended Battery (Music):

100Ah

Width:

5.4 in / 13,6 cm

Length:

8.9 in / 22,7 cm

Height:

2.2 in / 5,5 cm

Weight:

3.39 lb / 1,54 Kg.
