Audio-Technica VM520EB, kartridžas

Magnetinis Stereo Kartridžas su dvigubu magnetu.

  • Dažnių juosta: 20 - 23.000 Hz.
  • Kantileveris: Aliuminis.
  • Kanalų atskirtis: 27 dB (1 kHz).
  • VM tipo kartridžas.



The VM520EB is part of the 500 Series in Audio-Technica’s new VM cartridge line – a line that harks back to A-T’s early days as a manufacturer primarily of high-end phono cartridges, while also incorporating today’s advanced technology. Like all VM cartridges, the VM520EB is equipped with dual magnets that are positioned to match the left and right channels in the stereo record groove for outstanding channel separation and extended frequency response. The cartridge’s 0.3 x 0.7 mil elliptical bonded stylus tracks the record groove with high accuracy for outstanding audio reproduction. Includes mounting hardware.


    SPECIFIKACIJOS

    Frequency Response 20-23,000 Hz
    Channel Separation 27 dB (1 kHz)
    Vertical Tracking Angle 23°
    Stylus Construction Bonded round shank
    Recommended Load Impedance 47,000 ohms
    Coil Impedance 2,700 ohms (1 kHz)
    DC Resistance 800 ohms
    Coil Inductance 460 mH (1 kHz)
    Output Voltage 4.5 mV (at 1 kHz, 5 cm/sec)
    Output Channel Balance 1.5 dB (1 kHz)
    Stylus Shape 0.3 x 0.7 mil elliptical
    Cantilever Aluminum pipe
    Static Compliance 35 x 10-6 cm/dyne
    Dynamic Compliance 8 x 10-6 cm/dyne (100 Hz)
    Mounting Half-inch
    Dimensions 17.3 mm (0.7") H x 17.0 mm (0.7") W x 28.2 mm (1.1") D
    Accessories Included Four cartridge installation screws (5 mm x 2, 10 mm x 2), two washers, two hexagon nuts
    Mounting Feature Half-inch mount
    Recommended Load Capacitance 100-200 pF
    Replacement Stylus VMN20EB
    Stylus Size 0.3 x 0.7 mil
    Type VM Type
    Weight 6.4 g (0.2 oz)
