Focal ACX 690, Koaksialiniai automobiliniai garsiakalbiai

Focal ACX 690, Koaksialiniai automobiliniai garsiakalbiai

Trijų juostų koaksialiniai ACX 690 garsiakalbiai pasižymi neutraliu ir dinamišku garsu, tiksliais aukštaisiais dažniais ir geresne garso sklaida.

• Rekomend. stiprintuvo galia: 80 W.
• Jautrumas (2,83 V/1 m): 92 dB.
• Dažnių diapazonas: 50 Hz - 21 kHz.
• Varža: 4 Ω.

ACX 690 is the only 3-way kit in the Auditor line. Measuring 6 ^1/2” x 9 ^1/4” (16.4 × 23.5cm) and with an elliptical profile, this coaxial kit provides a large sound diffusion surface while reducing the height of the product to deliver deep bass and is easy, quick and invisible to install in the vehicle.
Like all the Auditor kits, it has a polypropylene cone and an adjustable, inverted dome mylar tweeter for precise treble and an improved soundstage.
ACX 690 can be linked with other electronics or directly connected to the vehicle’s original amplifier to enhance your in-car listening experience. Its high sensitivity guarantees an unrivalled level of performance in its category. It is perfect for a début Focal system and/or for improving your original sound system.

SPECIFIKACIJOS

• Type: 2-way elliptic coaxial kit
• Woofer: 164x235 mm
• Depth: 78 mm
• Cone: Polypropylene
• Maximum power: 160 W
• Nominal power: 80 W RMS
• Sensitivity (2.83V/1m): 92 dB
• Frequency response: 50 Hz - 21 kHz
• Impedance: 4 Ω
• Voice-coil diameter: 35 mm
• Magnet: Ferrite
• Suspension: Butyl
• Tweeter: Inverted dome tweeter
• Crossover: Integrated

INSTRUKCIJOS

User Manual (EN).
