Hertz HCP 4DK, automobilinis garso sitprintuvas

Automobilinis, 4-turių kanalų garso stiprintuvas užtirkins gamintojo deklaruojamą garso kokybe!

check_circle_outline highlight_off
Yra prekyboje Išparduota
Translation missing: lt.product.general.sku_html
Nuolaida: 343.00 €
Kaina: 343.00 €

Greitas užsakymas

Įveskite savo duomenis ir pateikite užsakymą. Mūsų vadybininkas susisieks su Jumis ir suderins visas pristatymo ir apmokėjimo detales.

Hertz HCP 4DK, automobilinis garso sitprintuvas

Automobilinis, 4-turių kanalų garso stiprintuvas užtirkins gamintojo deklaruojamą garso kokybe!

  • Galia: 150 W x 4 (4 Ω).
  • THD: 0.03%.
  • Lo-Pass bei Hi-Pass filtrai.
  • S/N Dažnis: 105 dB @ 1V.



The new HCP 4DK features latest generation D-Class 2Ω stable output stage reaching the impressive max power of 2000 W with the excellent S/N ratio of 105 dB. Extremely versatile, complete in its functions, provided with Speaker-In and RCA-In inputs to work with any head units, it has been designed to work also in mono (selectable mode), for a three-channel system with sub and front, or a powerful two-channels system. All the Hertz Compact Power amplifiers are assembled with high-quality components and feature a complete and by-passable crossover system. The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier.

  • e of the heatsink to effectively dissipate the heat generated by the electronic components. The internal temperature remains constant at all power levels.
  • COMPLETED FILTER SECTION

    Large array of filters customized for each model, to achieve maximum versatility: Lo-Pass, Hi-Pass, Band-Pass, Full Range, Bass Boost, Phase and Mono.
  • ART

    Automatic Remote Turn-On/Off function, automatically turns the amplifier on and off with the OEM radio; eliminates the need for a remote signal from the source when using the Speaker-In. This function can also be disabled.




SPECIFIKACIJOS

Channel mode 4 - 3 - 2
Output Power (RMS)
@ 14.4 VDC
4 Ch: 150 W x 4 (4 Ω)
4 Ch: 250 W x 4 (2 Ω)
3 Ch: 150 W x 2 (4 Ω) + 520 W x 1 (4 Ω)
3 Ch: 250 W x 2 (2 Ω) + 520 W x 1 (4 Ω)
2 Ch: 520 W x 2 (4 Ω)
Filters
Bypass
Hi-Pass
Lo-Pass
Band-Pass
Subsonic

Yes
A/B: 50 ÷ 3.2k Hz @ 12 dB/Oct.
A/B: 50 ÷ 3.2k Hz @ 12 dB/Oct.
-
No
Distortion - THD
(100Hz @ 4Ω)
0.03%
S/N Ratio
(A weighted @ 1V)
105 dB
Damping factor
(100Hz @ 4Ω)
200
Size W x D x H
mm (in.)
315 x 190 x 50 (12.40 x 7.48 x 1.97)



INSTRUKCIJOS

User Manual (EN).
