Monitor Audio Creator W2L, į sieną montuojama garso kolonėlė

INFORMACIJA

Monitor Audio Creator W2L - aukštos klasės 3 juostų į sieną montuojama kolonėlė, sukurta reiklioms namų kino ir stereo sistemoms. Joje naudojami keturi 5" RST II žemų dažnių garsiakalbiai, 3" RST II vidutinių dažnių garsiakalbis ir 1" C-CAM aukštadažnis su UD Waveguide II, todėl atkuriamas detalus, dinamiškas ir natūralus garsas. Uždara akustinė konstrukcija, 225 W nuolatinė galia ir iki 117 dB maksimalus garso slėgis leidžia W2L naudoti galingose namų kino sistemose. Quik-Link jungtis palengvina kabelių prijungimą, o Tri-Grip II sistema užtikrina greitą ir patikimą montavimą sienoje.

Dažnių diapazonas: 38 Hz–35 kHz
Jautrumas: 88 dB
Nominali varža: 4 Ω
Minimali varža: 4,2 Ω @ 1,1 kHz
Maksimalus SPL: 117 dB
Nuolatinė galia: 225 W
Rekomenduojama stiprintuvo galia: 110–450 W prie 4 Ω / 50–225 W prie 8 Ω

Kaina nurodyta už 1 vnt.

APRAŠYMAS

This large-sized Tier 2 in-wall loudspeaker is a three-way model featuring four RST II bass drivers, an RST II midrange driver, and a C-CAM tweeter. It has a cut-out dimension of 880 x 202 mm and a revolutionary Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable, and strong installation and fitting.

Features at a glance:
Ideal for installations where pristine acoustic performance is required  | Three-way design  |  1 x 1" C-CAM tweeter with UD Waveguide II for lifelike sound  |  1 x 3" RST II midrange driver  |  4 x 5" RST II bass drivers  |  Quik-Link speaker cable connector for quicker installation  |  Tri-Grip II for easy and secure fitment

"Incredible detail and musicality".
- Ecoustics

British High-Fidelity Architectural Sound Redefined
This large-sized Tier 2 in-wall loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a three-way model featuring four RST II bass drivers, an RST II midrange driver, and a C-CAM tweeter. This combination of clear and lifelike high-fidelity sound is of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 880 x 202 mm and uses the Quik-Link speaker cable connector, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable, and strong fitment.

How Your Reviews Drive Monitor Audio's Excellence
At Monitor Audio, we strive for audio excellence, and your feedback on Trustpilot is crucial to our journey. In today's market, trust is built on authentic experiences. Your reviews provide invaluable insights for potential customers, guiding them towards the superior, high-fidelity sound and quality, that Monitor Audio delivers. By sharing your thoughts, you directly influence our commitment to continuous improvement, helping us refine our products and services to meet your highest expectations.

TECHNINIAI DUOMENYS

System Format
3–Way

Frequency Response, Installed (-6dB)
38 Hz – 35 kHz

Sensitivity (2.83Vrms@1m, Installed)
88 dB

Nominal Impedance
4 Ohms

Minimum Impedance (20Hz to 20kHz)
4.2 Ohms @ 1.1 kHz

Maximum Peak SPL (AES75, Z-weighted)
117 dB

Continuous Power Handling (CTA 426-B)
225 W

Recommended Amplifier Power
(RMS, Music Signal)
110 – 450 W into 4 ohms
50 – 225 W into 8 ohms

Bass Alignment
Sealed

Crossover Frequency
LF/HF: 700 kHz
MF/HF: 3 kHz

Drive Unit Complement
4 x 5" (127 mm) RST II bass driver
1 x 3" (76 mm) RST II midrange driver
1 x 1" (25 mm) C-CAM tweeter

Mounting Depth
85 mm (33/8")

Cutout L x W
880 x 202 mm (345/8 x 715/16")

Pre-Construction Bracket
WL-B

External Dimensions with all accessories fitted (H x W x D)
909 x 231 x 93 mm (3513/16 x 91/16 x 35/8")

Weight (each)
With grille 7.77 kg (17 lb 2 oz)
Without grille 6.92 kg (15 lb 4 oz)

Cabinet Finish
Matte black & Orange & Bronze

Sold As
Single Unit

Warranty
Lifetime

DOKUMENTAI

Greito paleidimo vadovas (EN)
Vartotojo vadovas (EN)
