Naim XPS DR, Maitinimo Šaltinis
XPS yra paprastas ir efektyvus atnaujinimas tam, kad sutvirtinti muzikos atkūrimo galimybes Jūsų Naim sistemai. Kaip vienas iš mūsų laksčiausų komponentų jis gali būti naudojamas atnaujinti mūsų CDX2 CD grotuvą ir DAC skaitmeninį / analoginį keitiklį ir taip pat gali būti naudojamas mūsų NDS, NDX ir ND5 XS tinklo grotuvams ir HDX kietojo disko grotuvui/serveriui.
- Galios išėjimas: ±22V, ±10V, 2x 15V
- Maitinimo šaltinis: 100V, 115V, 230V; 50 ar 60Hz.
APRAŠYMAS
The XPS is a simple and effective upgrade to enhance the music-making ability of your Naim Audio source component. As one of our most flexible performers it can be used to upgrade our CDX2 CD player and DAC digital to analogue converter, and it is also suitable for use with our NDS, NDX and ND5 XS network players and HDX hard-disk player/server. Its large toroidal transformer features four separate windings, coupled to six low-noise regulators and benefits from Naim Audio DR voltage regulator technology
- Four isolated transformer windings with six low-noise DR power regulators - configured as two isolated regulators for digital at +15V, isolated +/-10V for DACs and isolated +/-23V for analogue stages
- All-new Discrete Regulator (DR) configuration, delivering Naim Audio’s best-ever standards of stable, low-noise power
- Brushed, black-anodised aluminium chassis plus anti-vibration feet
Use to upgrade the onboard DAC of the CD5 XS and CDX2 CD players and the HDX hard disk player/server
The Naim Audio XPS is a highly sophisticated power supply with six separately regulated, very low noise outputs, featuring a toroidal transformer and six power regulators. These supplies are branched and re-regulated, some twice in the CD player.
The addition of anti-vibration, resonance-controlling feet complement the elegant cast and extruded anti-magnetic chassis protect the sensitive internal components from resonance and microphonic vibration.
The XPS was updated in 2012 as a result of a two year project to develop a new discrete regulator (DR) for Naim Audio power supplies. The new Naim Audio DR now features, alongside improvements to the mechanical decoupling and internal layout. These enhancements, developed through intensive listening tests, significantly raise performance and make music even more communicative and enjoyable.
A technical white paper on the Naim Audio Discrete Regulator technology is available here.
Please note: only new classic series XPS units are compatible with the NDX network player, not ‘Olive’ versions. The old ‘Olive’ XPS is still compatible with CDX and CDS model CD players, the HDX hard disk player and the DAC digital to analogue converter however. Please consult your Naim Audio retailer if you are unsure of compatibility.
TECHNINIAI DUOMENYS
SPECIFIKACIJOS
| Case |
Black powder coated |
| Front |
Brushed and black anodised |
| Power Outputs |
± 22V, ± 10V, 2 x 15V |
| Shipping Weight |
15.1 kg |
| Shipping Dimensions |
240 x 590 x 500mm |
| Weight |
12.4 kg |
| Dimensions (HxWxD) |
87 x 432 x 314mm |
| Mains Supply |
100V, 115V, 230V; 50 or 60Hz |
| Supplied with |
Burndy |
| Other |
Power-Line Lite mains cable (UK denominations only) |
