Bevielis mikrofonas Takstar TS-8808

Bevielis mikrofonas Takstar TS-8808

• UHF wide frequency band design provides 200 selectable channels, multiple sets of system can be used simultaneously
• D-PLL RF frequency lock technique for accurate frequency and stable performance
• Twice frequency conversion receiving technique features high interference-resistant capability
• Professional audio companding technique for reducing the noise and increasing the dynamic range
• Button lock function on receiver prevents mis-operation
• Transmit power switching function for reducing radiation and extend the battery life when switching to low transmit power under short operating range
• Adjustable receiving sensitivity function for desired receiving effect or operating range according to actual environment
• Receiver and transmitters feature intuitive working status LCD for convenient use

Specification:

• Frequency Range: 740-790MHz
• Modulation Mode: FM
• Bandwidth: 50MHz
• Number of Frequencies: 200
• Frequency Spacing: 250KHz
• Frequency Steadiness: within ±0.005ï¼…
• Dynamic Range: ＞100dB
• Max. Frequency Deviation: ±45KHz
• Frequency Response: 80Hz-18KHz(±3dB）
• S/N Ratio: ＞105dB A+
• Total Harmonic Distortion: ≤1.0ï¼…

Receiver Specification:

• Receiver Mode: Double frequency conversion superheterodyne
• Intermediate Frequency: First: 110MHzï¼› Second: 10.7MHz
• Antenna Interface: TNC/50Ω
• Sensitivity: 12 dB μ V (80dBS/N)
• Sensitivity Space: ï¼š12-32 dBμV
• Spurious Suppression: ≥75dB
• Max. Output Level: +10dBV

Transmitter Specification:

• Output Power: High power 10mWï¼›Low power 3mW
• Spurious Suppression: -60dB
• Power Supply: 2pcs AA batteries
• Operating Time: More than 10 hours under power 10mW, more than 15 hours under power 3mW

Application:

• Classroom, karaoke, home entertainment, live performance

Product Content:

• TS-8808 Receiver 1pc
• TS-8808 Transmitter 2pcs
• Audio Connecting Cable 1pc
• Power Adaptor 1pc
• Antenna 2pcs
• Rack Mount 1pair
• 1.5V Battery 4pcs
• User Manual 1pc
