2-Ohm Power Output - 300 Watts RMS x 1 channel
Total Peak Power Output - 415W
4-Ohm Power Output - 200 Watts RMS x 1 channel
- Dažnių diapazonas: 10 Hz - 320 Hz
- Kanalų skaičius : Mono / Subwoofer
- Jautrumas: 98 dB
- Matmenys: 52 x 291 x 206 mm
Equipped with both low-level and high-level inputs
The GX-A3001 is equipped with both low-level and high-level inputs, allowing conncetion to virtually any factory or aftermarket head unit. Low-level input is made via standard RCA connectors and high-level inputs made via a supplied Molex connector and harness.
The 12dB per octave low-pass electronic crossover is infinitately variable from 32Hz - 320Hz and provide precision tuning of subwoofer in a variety of enclosure types.
Bass Boost circuit
The GX-A3001 also has an onboard bass boost circuit with is centered at 45Hz and is variable from 0dB - 12dB.
Powerful and Compact 415-Watt Subwoofer Amplifier
A 415-watt mono subwoofer amplifier with on-board variable electronic crossover, the GX-A3001 features a compact footprint of just 2-1/16" (52mm) high, 9-1/8" (206mm) wide and 11 7/16" (291mm) deep. This tiny powerhouse includes a cast-aluminum heat sink, built-in electronic crossover networks, and enough power to drive your woofers to distraction. With almost seven decades of experience in bringing live music to life, JBL® has adapted many of our professional technologies for use in our car audio systems, transforming your road-going listening experience with new levels of power and clarity. Whether you’re looking at dramatically improving the sound of your factory installed audio system or designing a world-class competitive sound system from the chassis up, your JBL car audio retailer has everything you’re looking for. Crank up both the volume and the fidelity of your factory-installed sound system with the new GX Series amplifiers. Ranging from a compact stereo amplifier with enough power to drive the most demanding speaker systems, to the thunderous GX-A3001 with well over 400 watts of raw bass power to shake the ground, GX amplifiers cover the range at surprisingly affordable prices. There’s nothing wrong with your existing audio system that real power can’t fix, and GX series amps make adding that power easy. Setting up a sound system to fill your car takes not only great gear, but the ability to make all the components work together as an integrated whole. On board active crossovers and separate line- and speaker-level inputs make it easy to tie the new GX amps to the rest of your system, and carefully engineered Bass Boost circuits make it easy to get the sound you crave, whether you’re upgrading a factory system or building from scratch. For years, JBL’s engineers have made the gear that experts have relied on. Now, we also make gear that helps you perform like an expert.
- Frequency Response 10Hz-320Hz
- 2-Ohm Power Output 300 Watts RMS x 1 channel
- Variable Bass Boost 0 to + 12dB @45Hz
- Signal-to-Noise Ratio 98dB
- Input Sensitivity100mv-20V
- Total Peak Power Output 415W
- 4-Ohm Power Output 200 Watts RMS x 1 channel
- THD + Nless than 1%
- Cast-aluminum heat sink
- Built-in electronic crossover networks
- Power to drive your woofers to distraction
