Garso stiprintuvas Helix A4, High-End

4 kanalų High-end garso stiprintuvas su integruotu aktyviu crossover.

• Galia RMS / MAX:
  @ prie 4 omų - 4 x 85W / 150W
  @ prie 2 omų - 4 x 150W / 250W
  Tiltu @ prie 4 omų - 2 x 270W / 450W
  Tiltu @ prie 2 omų - 2 x 395W / 650W
• Dažnių diapazonas: 15 Hz - 20,000 Hz
• Bass boost: 0 - 9 dB / 30 - 120 Hz
• Damping faktorius: > 450
• Įėjimo jautrumas: 500 mVolts - 8 Volts
• Matmenys: 35 x 432 x 240 mm

OVERVIEW

There are lots and lots of powerful amps out there – but only those that unconditionally control the connected loudspeakers with a grip of iron and an extremely high damping factor bear the name of HELIX. The output stages of the competition line are what the high ender calls “wired for power”. Whether it’s sheer power or enormous musical sensitivity – these power packs know every trick in the book. If you fi nally want to stop looking for the perfect amp, then this is where the search will end.

FEATURES

• Extremely stable ouput stage with selected MOSFET transistors
• Drivers in Class A Technology for lowest possible THD
• Processor-controlled technology for optimized operation
• Smart protection circuits against overheating, over- and undervoltage, speaker short circuiting, low impedance and faulty connection
• 1 % accurate components for perfect sound quality
• 24 carat gold-plated solid connection terminals suitable for 25 mm² / gauge 4
• Temperature-optimised heatsink for effi cient heat dissipation

TECHNINIAI DUOMENYS

• Highpass: 15 - 7,000 Hz adjustable
• Lowpass: 15 - 7,000 Hz adjustable
• Bandpass: 15 - 7,000 Hz adjustable
• Distortion: < 0.009 %
• Signal-to-noise ratio: > 100 dB

DOKUMENTAI

Vartotojo vadovas
