Hertz HCP 4, automobilinis garso sitprintuvas

Automobilinis, 4-turių kanalų garso stiprintuvas užtirkins gamintojo deklaruojamą garso kokybe!

  • Galia: 65 W x 4 (4 Ω).
  • THD: 0.01%.
  • Lo-Pass bei Hi-Pass filtrai.
  • S/N Dažnis: 103 dB @ 1V.



HCP 4 is a four channels car audio amplifier designed to reproduce any musical genres with four separate channels for multiple configurations. Pre-amplified (Pre-In) inputs and high-level (Speaker-In) inputs allow for connection with any head units. Built to work both in mono, as part of a three-channel system with sub and front, and in stereo for a powerful two-channel system, HCP 4 is a unique model in terms of versatility!

All the Hertz Compact Power amplifiers are assembled with high-quality components and feature a complete and by-passable crossover system. The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier.



  • REFINED HEATSINK WITH HIGH CONVECTION CAPABILITY

    The extruded aluminum heatsink provides high efficiency thermal performance; using the top side of the heatsink to effectively dissipate the heat generated by the electronic components. The internal temperature remains constant at all power levels.
  • COMPLETED FILTER SECTION

    Large array of filters customized for each model, to achieve maximum versatility: Lo-Pass, Hi-Pass, Band-Pass, Full Range, Subsonic, Bass Boost, Phase and Mono. Filtered pre-amplified outputs along with multiple adjustments are featured on the HCP 1D, offering the user endless connection possibilities with any source.
  • HCP ELECTRONICS

    Special balanced input circuitry rejects electro-magnetic disturbances present on the Pre-amplified or Speaker level inputs. Power supply stage features a multiple winding transformer and Low-ESR 105°C capacitors, selected to ensure high efficiency and current capability.
  • ART

    Automatic Remote Turn-On/Off function, automatically turns the amplifier on and off with the OEM radio; eliminates the need for a remote signal from the source when using the Speaker-In. This function can also be disabled.
  •




    SPECIFIKACIJOS

    Channel mode 4 - 3 - 2
    Output Power (RMS)
    @ 14.4 VDC
    4 Ch: 65 W x 4 (4 Ω)
    4 Ch: 95 W x 4 (2 Ω)
    3 Ch: 65 W x 2 (4 Ω) + 190 W x 1 (4 Ω)
    3 Ch: 95 W x 2 (2 Ω) + 190 W x 1 (4 Ω)
    2 Ch: 190 W x 2 (4 Ω)
    Filters
    Bypass
    Hi-Pass
    Lo-Pass
    Band-Pass


    Yes
    A/B: 80 Hz @ 12 dB/Oct.
    A/B: 50 ÷ 500 Hz @ 12 dB/Oct.
    -

    Distortion - THD
    (100Hz @ 4Ω)
    0.01%
    S/N Ratio
    (A weighted @ 1V)
    103 dB
    Damping factor
    (100Hz @ 4Ω)
    120
    Size W x D x H
    mm (in.)
    315 x 190 x 50 (12.40 x 7.48 x 1.97)



    INSTRUKCIJOS

    User Manual (EN).
