Lumin

Lumin AMP, Stereo stiprintuvas (įvairių spalvų)

12,990.00 €

Lumin AMP, Stereo stiprintuvas (įvairių spalvų) - Juoda yra užsakytas ir bus išsiųstas, kai tik bus sandėlyje.

Siuntimas ir pristatymas

Prekes visoje Lietuvoje (išskyrus Kuršių Neriją) pristato skubių siuntų tarnyba "Venipak" per 1-2 darbo dienas, tiesiai į namus ar darbovietę. Pristatymas yra nemokamas, jeigu prekių suma viršija 100€, kitu atveju taikomas 4,99€ pristatymo mokestis. Kurjeris pieš atveždamas prekes su Jumis susisieks Jūsų nurodytu telefono numeriu ir suderins pristatymo laiką.

LUMIN AMP dėmesys sutelktas tik į našumą. Su šiuo stiprintuvu Jūsų garso sistema skambės tarsi gaivaus oro gurkšnis, pasiruoškite jį perkelti į kitą lygį.

  • Galia: 320W 4Ω.
  • AB klasės stiprintuvas.
  • Stereo, Dual Mono ar Bridged variacijos.
  • Dažnių juosta: 20hz - 40000hz ± 0.1db.





Matched styling.
Unmatched performance.

  • Multi-Stage transistors amplifier
  • Dual Mono power supply and amplifier design
  • Fully discrete voltage and current gain stages
  • DC-coupled signal path
  • Class AB operation
  • High input impedence and sensitivty for direct DAC drive
  • Intelligent bias and thermal management
  • Stereo / Dual Mono / Bridged operation
  • CNC single billet aluminium construction
  • 600VA custom toroidal transformer
  • Built-in overload, overheat and DC protection

True Dual Mono design throughout

Keeping the design Dual Mono all the way from the power supply delivers full power simultaneously from both channels and keeps crosstalk to an absolute minumum.

In LUMIN Amp, each channel is a mirror image of the other.

Discrete Transistors

Fully discrete voltage and current gain operating in class AB to deliver the finest details with the lowest distortion from your music.

Custom low-noise toroidal power supply

LUMIN Amp features a unique completely separate dual mono power supply design.

The ultra low noise design features advanced voltage regulation circuitry.



      SPECIFIKACIJOS

      SPECIFICATION

      LUMIN AMP SPECIFICATION

      • OPERATING MODE: (selectable)

        • Stereo, Dual Mono or Bridged mode

      • INPUT: (selectable)

        • 1 x XLR pair (pin 2 hot), 1 x RCA pair

      • POWER:

        • 160W per channel into 8Ω
        • 320W per channel into 4Ω
        • 640W into 8Ω (Bridged)

      • POWER SUPPLY:

        • Available in 220–240V AC and 110–120V AC versions ~ 50/60Hz

      • POWER CONSUMPTION:

        • Standby <0.5W
        • Idle 40W
        • Max 700W

      • FREQUENCY RESPONSE:

        • 20hz - 40000hz ± 0.1db

      • SIGNAL TO NOISE RATIO:

        • 103db, unweighted

      • INPUT IMPEDANCE:

        • 200kΩ Balanced (XLR)
        • 100kΩ Unbalanced (RCA)

      • OUTPUT IMPEDANCE:

        • 0.1Ω

      • INPUT SENSITIVITY:

        • 1.16Vrms

      • GAIN:

        • +26dB (Stereo, Dual Mono)
        • +32dB (Bridged)

      • PROTECTION:

        • DC, overload and overheating protection

      • FINISHES:

        • Black anodized brushed aluminium or Raw brushed aluminium

      • CONSTRUCTION:

        • CNC-machined from a single billet for front, top and sides. Thick 8mm walls, rear panel and base plate

      • DIMENSIONS:

        • 350mm (W), 374mm (D), 104mm (H)

      • WEIGHT:

        • 19kg

      Kategorijos

      Lumin AMP, Stereo stiprintuvas (įvairių spalvų)
      Lumin

      Lumin AMP, Stereo stiprintuvas (įvairių spalvų)

      12,990.00 €

      LUMIN AMP dėmesys sutelktas tik į našumą. Su šiuo stiprintuvu Jūsų garso sistema skambės tarsi gaivaus oro gurkšnis, pasiruoškite jį perkelti į kitą lygį.



      APRAŠYMAS



      Matched styling.
      Unmatched performance.

      True Dual Mono design throughout

      Keeping the design Dual Mono all the way from the power supply delivers full power simultaneously from both channels and keeps crosstalk to an absolute minumum.

      In LUMIN Amp, each channel is a mirror image of the other.

      Discrete Transistors

      Fully discrete voltage and current gain operating in class AB to deliver the finest details with the lowest distortion from your music.



      Custom low-noise toroidal power supply

      LUMIN Amp features a unique completely separate dual mono power supply design.

      The ultra low noise design features advanced voltage regulation circuitry.



          TECHNINIAI DUOMENYS

          SPECIFIKACIJOS

          SPECIFICATION

          LUMIN AMP SPECIFICATION

          • OPERATING MODE: (selectable)

            • Stereo, Dual Mono or Bridged mode

          • INPUT: (selectable)

            • 1 x XLR pair (pin 2 hot), 1 x RCA pair

          • POWER:

            • 160W per channel into 8Ω
            • 320W per channel into 4Ω
            • 640W into 8Ω (Bridged)

          • POWER SUPPLY:

            • Available in 220–240V AC and 110–120V AC versions ~ 50/60Hz

          • POWER CONSUMPTION:

            • Standby <0.5W
            • Idle 40W
            • Max 700W

          • FREQUENCY RESPONSE:

            • 20hz - 40000hz ± 0.1db

          • SIGNAL TO NOISE RATIO:

            • 103db, unweighted

          • INPUT IMPEDANCE:

            • 200kΩ Balanced (XLR)
            • 100kΩ Unbalanced (RCA)

          • OUTPUT IMPEDANCE:

            • 0.1Ω

          • INPUT SENSITIVITY:

            • 1.16Vrms

          • GAIN:

            • +26dB (Stereo, Dual Mono)
            • +32dB (Bridged)

          • PROTECTION:

            • DC, overload and overheating protection

          • FINISHES:

            • Black anodized brushed aluminium or Raw brushed aluminium

          • CONSTRUCTION:

            • CNC-machined from a single billet for front, top and sides. Thick 8mm walls, rear panel and base plate

          • DIMENSIONS:

            • 350mm (W), 374mm (D), 104mm (H)

          • WEIGHT:

            • 19kg
