Monitor Audio

Monitor Audio CP-WT380IDC, sieninis garsiakalbis

€725.00 EUR

Monitor Audio CP-WT380IDC, sieninis garsiakalbis - prieš pirkdami pasiteiraukite ar šią prekę turime sandėlyje, jei neturime ji gali būti užsakyta ir atvykti per 2-21 dieną.

Neišsirenkate garso kolonėlių namams? Turime Jums sprendimą!
Kviečiame atvykti garso aparatūros perklausai.

Pristatymas į namus nuo 4.99 €

Venipak kurjeriu per 1-2 darbo dienas.

Atsiimkite parduotuvėje 0 €

Armatūrininkų g. 1, Kaunas
Darbo laikas: I-V 9:00-18:00

Į sieną montuojamas garsiakalbis iš Monitor Audio.  Garsiakalbis perteikia garsą stipriai bei itin aiškiai. Todėl jo skambesį įvertints, net išrankiausi! Tai vienas galingiausių šios serijos garsiakalbių!

  • Galia: 120 W.
  • Dažnių juosta: 50 Hz – 30 kHz.
  • Jautrumas: 89 dB.
  • Varža: 6 Omai.

Technology
  • Pivoting IDC C-CAM gold dome tweeter.
  • Pivoting module consisting of IDC midrange driver and C-CAM Gold Dome tweeter.
  • C-CAM bass driver featuring Rigid Surface Technology (RST).
  • High overall efficiency.
  • High frequency level adjustment (+/-3 dB).
  • Midrange frequency level adjustment.
  • Boundary compensation controls.
  • Die-cast aluminium front baffle.
  • Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
  • Magnetic and easily removable steel grille.
  • Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
  • Airtight enclosure design, which protects each precision-engineered driver system against the damaging ingress of dust and dirt.

SPECIFIKACIJOS
Frequency Response

50 Hz – 30 kHz
Nominal Impedance

6 ohms
Sensitivity (1W@1M)

89 dB
Maximum SPL

109.6 dBA
Power Handling (RMS)

120 W
Recommended Amplifier Requirements

30 – 120 W
Crossover Frequency

Bass low pass: 300 Hz @ 6 dB / Octave
Mid: 300 Hz @  6 dB / Octave
& 3 kHz @ 12 dB / Octave
Drive Unit Complement

3-Way
8" C-CAM RST cone bass driver
4" C-CAM IDC cone mid range driver
1" C-CAM Gold Dome tweeter
(tweeter & midrange driver combined in a pivoting module)
Adjustment Controls

HF Level Switch (+3 dB / 0 dB / -3 dB)
MF Level Switch (+3 dB/ 0 dB/ -3 dB)
Boundary Compensation Switch
Overall Dimensions (H x W x D)

472.5 x 303.5 mm (185/8 x 1115/16")
Overall Depth (Including Grille)

106 mm (43/16")
Cut-Out Dimensions

438 x 269 mm (171/4 x 109/16")
Mounting Depth

99 mm (37/8")
Fixing Type

6 position Tri-Grip dog leg fixings
Construction Material

Mineral Filled ABS Plastic (RoHS2 Compliant)
Weight

5.62 kg (12 lb 6 oz)
Pre-Construction Bracket

WB10 Pre-Construction Bracket (Light Brown)
Sold As

Single Unit

INSTRUKCIJOS

User Manual (EN).
