Pro-Ject Pre Box RS Digital, Hi-End prardinis stiprintuvas su DAC

"Pre Box RS Digital" sujungia visas "DAC Box RS" funkcijas ir labai linijinį išankstinį stiprintuvą su puslaidininkiniais ir lempiniais išėjimo laipsniais, kuriuos galima pasirinkti pakaitomis.

check_circle_outline highlight_off
Yra prekyboje Išparduota
Translation missing: lt.product.general.sku_html
Nuolaida: 1,299.00 €
Kaina: 1,299.00 €

Greitas užsakymas

Įveskite savo duomenis ir pateikite užsakymą. Mūsų vadybininkas susisieks su Jumis ir suderins visas pristatymo ir apmokėjimo detales.

Pro-Ject Pre Box RS Digital, Hi-End prardinis stiprintuvas su DAC

"Pre Box RS Digital" sujungia visas "DAC Box RS" funkcijas ir labai linijinį išankstinį stiprintuvą su puslaidininkiniais ir lempiniais išėjimo laipsniais, kuriuos galima pasirinkti pakaitomis.

  • Perjungiami DAC lustai: 2x PCM1792 arba PCM5102.
  • 9 skaitmeninės įvestys: i²S, AES/EBU, Toslink, S/PDIF coax.
  • Analoginis: XLR/RCA/ ausinių išvestis, RCA įvestis.
  • Ausinių stiprintuvas su pritaikoma išėjimo varža.

Pre Box RS Digital combines all features of DAC Box RS plus a very linear pre-amplifier with both solid-state and tube output stages, that can be selected alternatively. As in all our top-class digital products, we use PCM1792 DAC chips from Texas Instruments, but here we use 2 pieces in a dual differential mode to achieve ultimate fidelity. As a selectable feature, a second DAC chip from Texas Instruments is on board, that can handle 32bit/384kHz. A high-class headphone output with selectable impedance for a perfect match to your headphones is also provided. Pre Box Digital RS offers 3-dimensional sound-staging, perfect micro dynamics and ultimate resolution combined with flexibility to use a wide range of digital and 1 analogue sound sources. Perfectly combined with Pro-Ject CD Box RS disc drive, Pre Box RS Digital will give outstanding sound experience, because of a I²S connection provided via RJ45, that is able to give jitter-free disc playback.

Features

  • Switchable DAC chips: 2x PCM1792 or PCM5102
  • 9 digital inputs: i²S, AES/EBU, Toslink, S/PDIF coax
  • Analogue: Pre-out XLR/RCA/headphone, RCA input
  • Headphone amp with adaptable output impedance
  • Fully balanced double mono design
  • Output stage switchable between 6922 tube & solid state
  • Ultra-linear and ultra low noise
  • Pure Class A circuitry
  • Blue Alps volume control
  • DC power supply (< 1 watt standby power)
  • IR remote control included
  • Available in black and silver



    SPECIFIKACIJOS

    DAC DAC1 – 2 x PCM1792 24bits/192k Hz;
    DAC2 – PCM5102 32bits/384k Hz
    Tubes 2 x 6922 EH
    Digital inputs 1 x USB 2.0 Audio 32/384 + DoP-DSD 64/128
    1 x RJ45 Sonic I2S for CD Box RS in Sonic Mode
    2 x S/PDIF 24/192
    4 x S/PDIF Optical 24/96
    1 x AES/EBU balanced 24/192
    Line-level input 1 RCA/phono sockets
    Input impedance 33 kohms
    Analog outputs Pre-out (XLR & RCA), Headphone (6,35mm jack)
    Headphone impedance 5 / 20 / 50 Ohms switchable
    Analog input sensitivity 1.6V RMS for full headphone output
    Frequency response 20 Hz - 50 kHz (+ 0dB/- 0.1 dB)
    Signal to noise ratio -100 dB (IEC-A)
    THD 0.005% solid state output/ 0.25% tube output
    Master clock output 16.9344 MHz for CD Box RS in Sonic Mode
    Outboard power supply 20 V/3 A DC suitable for your country's mains supply
    Power consumption 300 mA solid / 850 mA tube / 90 mA standby
    Dimensions W x H x D 206 x 72 x 210 mm with sockets
    Weight 1950 g without power supply

    INSTRUKCIJOS

    User Manual (EN).
